Focus Spot 4Z Operating Instructions
GAMMA ADJUSTMENT
- With this function, you are able to adjust the gamma setting. This feature is predomi-
nately used when shooting video.
1. Access the main menu, and press the UP or DOWN buttons until "Function" is higlighted, then press
ENTER.
2. Press the UP or DOWN buttons until "Gamma" is highlighted, and press ENTER. The current setting will
now be displayed.
3. Use the UP or DOWN buttons to find your desired setting.
4. Press the ENTER button to confirm your selection or press the MODE button to exit.
FREQUENCY ADJUSTMENT
- With this function, you are able to adjust the dimming frequency. This feature is pre-
dominately used when shooting video and achieving flicker free operation.
1. Access the main menu, and press the UP or DOWN buttons until "Function" is higlighted, then press
ENTER.
2. Press the UP or DOWN buttons until "Frequen" is highlighted, then press ENTER. The current setting will
now be displayed.
3. Use the UP or DOWN buttons to find your desired setting.
4. Press the ENTER button to confirm your selection or press the MODE button to exit.
FAN SET
- With this function, you can control the moving head fan speed.
1. Access the main menu, and press the UP or DOWN buttons until "Function" is higlighted, then press
ENTER.
2. Press the UP or DOWN buttons until "Fan Set" is highlighted, and press ENTER.
3. "Head Fan" will now be displayed, press ENTER.
4. Use the UP or DOWN buttons to make the adjustments to the fan.
5. Press the ENTER button to confirm your selection or press the MODE button to exit.
BACKLIGHT
- With this function you can have the LCD display backlight after 2-60 minutes. Use this func-
tion to adjust the time.
1. Press the MODE button to access the main menu. Press the UP or DOWN buttons until "Function" is high-
lighted, then press ENTER.
2. Press the UP or DOWN buttons until "LCD.Set" is highlighted, press ENTER.
3. Press UP or DOWN buttons, until "Backlight" is highlighted, and press ENTER.
4. "05m" (5 minutes) will be displayed, this is the default setting. Use the LEFT or RIGHT buttons to adjust the
shutoff time between 02m-60m or "Off".
5. Press the ENTER button to confirm your selection or press the MODE button to exit.
ADJ Products, LLC - www.adj.com - Focus Spot 4Z User Manual Page 21
