Focus Spot 4Z
Channel Modes & Values
Basic
1
2
3
4
5
ADJ Products, LLC - www.adj.com - Focus Spot 4Z User Manual Page 13
Standard Extended
1 1
2 2
3 3
4 4
5 5
6 6
7 7
Values
PAN Movement 8-bit:
000-255
Pan Movement By 630/540
Pan Fine 16-bit:
000-255
Fine control of Pan movement
TILT Movement 8-bit:
000-255
Tilt Movement
Tilt Fine 16-bit:
000-255
Fine control of Tilt movement
Color Wheel:
000-007 White
008-014 Red
015-021 Orange
022-028 Yellow
029-035 Green
036-042 Blue
043-049 Pink
050-056 Cyan
057-063 Magenta
064-127 Color Mixing
128-189 Color Wheel Clockwise Rotation Fast-Slow
190-193 Nothing
194-255 Color Wheel Counter-Clockwise Rotation
Slow-Fast
Gobo Wheel
000-004 Open
005-019 Gobo 1
020-034 Gobo 2
035-049 Gobo 3
050-064 Gobo 4
065-079 Gobo 5
080-094 Gobo 6
095-109 Gobo 1 Shake Slow-Fast
110-124 Gobo 2 Shake Slow-Fast
125-139 Gobo 3 Shake Slow-Fast
140-154 Gobo 4 Shake Slow-Fast
155-169 Gobo 5 Shake Slow-Fast
170-189 Gobo 6 Shake Slow-Fast
190-221 Gobo Wheel Clockwise Rotation Fast-Slow
222-223 Nothing
224-255 Gobo Wheel Counter-Clockwise Rotation
Slow-Fast
Gobo rotation:
000-127 Gobo Rotation Indexing
128-191 Gobo Rotation Clockwise Fast-Slow
192-255 Gobo Rotation Counter-Clockwise Slow-Fast
DMX Modes & Values
Functions
