Focus Spot 4Z
The main menu is accessed by pressing the MODE button. Browse through the menu by using the UP,
DOWN, RIGHT, & LEFT buttons. Press the ENTER button to access the desired menu. You can scroll through
the submenus using the UP and DOWN buttons. To confirm every selection press the ENTER button. You
can exit every menu and submenu by pressing the MODE button. The unit will automatically exit the menus
if no buttons are pressed after 10 seconds. These next pages will explain each function in the system menu
located on the previous pages.
SET ADDRESS
- With this function, you can adjust and set your desired DMX address.
1. Access the main menu, and press the UP or DOWN buttons until "Receive" is higlighted, then press
ENTER.
2. "Set Address" will now be displayed, press ENTER. The current DMX address will now be displayed.
3. Use the UP or DOWN buttons to adjust the DMX address.
4. Press the ENTER button to confirm your address or press the MODE button to exit.
USER MODE
- This mode will let you select your desired DMX Channel mode.
1. Press the MODE button to access the main menu. Press the UP or DOWN buttons until "User Mode" is
highlighted, then press ENTER. Hightlight "User Mode" once again and press ENTER.
2. Use the UP or DOWN buttons to scroll through the 3 DMX Channel Modes. See the DMX channel modes
listed below. Press the ENTER button to confirm your selection or press the MODE button to exit.
• Basic Mode - This is 16 Channel Mode.
• Standard Mode - This is 18 Channel Mode.
• Extended Mode - This is 22 Channel Mode.
User Mode A B C - These are customizable DMX modes. Select either of these modes and set the amount of
DMX Channels and what each channel does.
3. Press the ENTER button to cofirm your settings or press the MODE button to exit.
NO DMX MODE
- With this function if the DMX signal is suddenly lost, the unit will automatically go into 1 of
3 modes.
1. Press the MODE button to access the main menu. Press the UP or DOWN buttons until "Function" is highlighted,
then press ENTER.
2. Press the UP or DOWN buttons until "Status" is highlighted, then press ENTER.
3. Press the UP or DOWN buttons, until "No DMX Mode" is highlighted, then press ENTER.
4. Either "Hold" (Last DMX setting), "Black" (Blackout), or "Auto" (Auto Program) will be displayed, use the
UP or DOWN buttons to scroll through the options.
5. Press the ENTER button to confirm your selection or press the MODE button to exit.
ADJ Products, LLC - www.adj.com - Focus Spot 4Z User Manual Page 18
