Local Network Connection

Page 2-10
Figure 2-7.
Secure the REX card to the chassis by tightening the screws are each side of
5.
the front panel until they are finger tight.
Attach the port labels provided in the accessory kit.
6.
End of Procedure
To connect the RAS 2000 PowerRack to your local Ethernet you use either the
10-Base-T or AUI connector on the Engine Card. To connect to the
10-Base-T network, you must supply the cable to plug into the RJ-45 connector.
To connect to the AUI connector requires the appropriate AUI transceiver and
cable, which you also must provide.
RAS 2000 PowerRack Hardware Guide
1 Card guide
2 Finger screw
Installing the REX Serial Card
