Hardware Overview
Figure 2-1 shows the RAS 2000 PowerRack front panel.
1
RISC-866 Engine Card
2
10 Base-T Connector
3
AUI Connector
4
Transmit LED
5
Receive LED
6
Collision Detect
NOTE: The status LED functions are defined in the RAS 2000 Software Supplement.
RAS 2000 PowerRack Hardware Guide
7
Link
8
Status Indictor LED
9
Status Indicator LED
10
Serial Port Connector
11
REX Card Expansion Slot
12
Activity Indicator LED
RAS 2000 Front Panel
Figure 2-1.
Page 2-3
