Installing the RAS 2000 PowerRack
Page 2-6
You can install the RAS 2000 PowerRack in a 19-inch rack or on a desk top. To
mount it in a rack, attach the mounting brackets (mounting "ears").
Desk Top Mounting
For desk top operation, attach rubber feet to the bottom of the unit. The mounting
accessory kit shipped with each RAS 2000 PowerRack contains mounting brack-
ets, rubber feet, and the screws needed for attaching them.
Figure 2-3.
Rack Mounting
Attach each rack mount bracket to the RAS 2000 PowerRack using the
#6-32
1
/
" black pan head Phillips screws for each bracket. Attach the brackets to
4
the front of the PowerRack or the back (see Figure 2-4). Some installers want the
Ethernet and serial cables to face the front of the rack enclosure and some want
them to the back. Install the brackets on the end that is to face the front.
RAS 2000 PowerRack Hardware Guide
1
Rubber foot
1
/
"
2
#6-32 x
4
black pan head Phillips screw
Installing the Mounting Feet
