Crestron CP4-R Product Manual page 55

Observe the following points when configuring source routes:
If two media sources are routed to a DM NVX device (via the Input 1 and Input 2
•
ports), both media sources may not be used at the same time. For example, if
switching from Input 1 to Input 2 in a media zone, all media zones where Input 1 is
selected switch to Input 2.
CEC devices must be routed manually to the HDMI® input that matches the
•
control port that was assigned to the device.
The 25 inputs provided for Crestron Connected AVR devices are generic, as each
•
AVR device has different input specifications. Refer to the AVR device's
documentation when configuring source routes to determine the appropriate
inputs to use for routing.
If the audio signal for a video source is routed to a SWAMP audio expander
•
endpoint, the audio signal will lag behind the video signal by a few seconds when
the source is selected. This behavior occurs because the SWAMP device is
warming up.
Tap the gear button
speaker channel.
Speaker Output Configuration
NOTE: The audio outputs of certain Crestron audio expanders may be bridged or bussed
by assigning two output channels to the same speaker output, and tapping the gear
button next to one of the outputs. A dialog box is displayed asking whether the
outputs should be bridged or bussed. For more information, refer to the device
documentation at www.crestron.com/manuals.
Product Manual – DOC. 8432A
next to an audio input or output channel to edit settings for the
Crestron Pyng OS 2 for CP4-R • 49
