Wood-mizer LT15 Series Safety, Setup, Operation & Maintenance Manual page 23

Vertical Mast Lock Assembly
Manaual Feed Assembly
SAWMILL ASSEMBLY
Table 1:
100903-1 Sawdust Chute
085981-1 Thick Spacer
Washer
Leg, LT15
100064-1
Stationary Bed
086743-1 Zinc-plated Pin
F81045-1 Roll Pin 6x50
F81044-21 Roll Pin 3x20
087301 Compression Spring
18x37x1.8
F81043-2 Cotter Pin S-Zn
4x25
F81058-1 Flat Washer 17
094191-1 Power Feed Crank
Handle
094142 Bushing
086338 Crank Handle Grip
F81033-1 Hex Nylon Lock Nut
M10
15doc120709
SAWMILL ASSEMBLY
Parts specifications
1
6
12 12
2
2
2
2
2
2
1
2
1
1
2
1
4
2
2
2
2
2
2
1
2
1
1
2-3
