Appendix A: References

1. "ACPL-337J 4 Amp Gate Drive Optocoupler with Integrated (VCE) Desaturation Detection, Active Miller Clamping, Fault

and UVLO Status Feedback," Broadcom Inc., AV02-4319EN.

https://docs.broadcom.com/docs/AV02-4391EN

2. "FUJI IGBT Module EP2 Package Evaluation Board," Fuji Electric MT6M13583 Rev. a.

http://www.fujielectric.com/products/semiconductor/model/igbt/evaluation/box/doc/pdf/MT6M13583a_E.pdf

3. "7MBR35XMA120-50 Power Module (X Series) 1200V/35A PIM Datasheet," Fuji Electric.

http://www.fujielectric.com/products/semiconductor/model/igbt/pim.html

4. "M57140-07F Datasheet", Isahaya Electronics Corporation.
