Swegon GOLD Function Manual page 5

5. Adjustment.
For basic particulars on how to handle the hand-held
micro terminal, see the Operation and Maintenance
Instructions for the GOLD unit.
The Xzone function must be manually activated, under
INSTALLATION – FUNCTIONS – IQNOMIC PLUS in the
hand-held terminal.
If postheating is required in the extra zone, activate No. A
XZONE HEATING by selecting what type of air heater is to
be connected, under FUNCTION ON/OFF.
If cooling is required in the extra zone, activate No. B
XZONE HEATING by selecting control function under
FUNCTION ON/OFF.
The neutral zone required between the heating and cool-
ing sequences must be set under SETTINGS.
We reserve the right to alter specifications.
INSTALLATION
FUNCTIONS
*FUNCTIONS*
TEMPERATURE
FLOW/PRESSURE
FILTER
OPERATION
HEATING
COOLING
MOISTURE
ReCO
2
IQNOMIC PLUS
*IQNOMIC PLUS*
NO. 9 PREHEATING
NO. A XZONE HEATING
NO. B XZONE COOLING
*XZONE HEATING*
FUNCTION OFF/ON
DEACTIVATE
EL AIR HEATER, P/P
EL AIR HEATER, 0 - 10 V
WATER COIL WITH FP
WATER C. WITHOUT FP
*IQNOMIC PLUS*
NO. 9 PREHEATING
NO. A XZONE HEATING
NO. B XZONE COOLING
*XZONE COOLING*
FUNCTION OFF/ON
SETTINGS
DEACTIVATE
STEPLESS 0 = 10 V
STEPLESS 10 = 0 V
ON/OFF, 1 STEP
ON/OFF, 2 STEPS
ON/OFF, 3 STEPS BINARY
*XZONE COOLING*
NEUTRAL ZONE
2.0°C.
GB.XZONE.080630
