S 2- Installing Your STS™ Transmitter
TEP
Place the STS™ Transmitter into the STS™ Sensor Pod with the flat side facing down.
Pull the STS™ Transmitter Latch up onto the to STS™ Transmitter to snap it into place.
Remove the STS™ Transmitter Latch by holding the end of the latch and quickly twisting off the latch away from your body.
Install STS™ Transmitter in STS™
Sensor Pod
Press any button on the STS™ Receiver to check for the Antenna icon (Y) before you
continue.
S

3- Beginning your Continuous Glucose Monitoring Session

TEP
Press the Down Arrow 3 times until you come to the 9-hour Glucose Trend Screen and then press and hold the Down
Arrow for at least 7 seconds until you see the Sensor Insertion Screen.
Press the OK button.
C M
ONTINUOUS ONITORING

Viewing your Glucose Trends

You can view trends and patterns using the 1-hour, 3-hour, and 9-hour glucose screens. (See screens below).
Glucose Value
Press
1-hour
Glucose Trend Screen Glucose Trend Screen
STS™ Receiver Alert Screens
The device may vibrate and/or beep and display one of the following screens during use:
Out of Calibration
Calibration Update
Screen
Screen
Caution: Investigational device. Limited by Federal (United States) law to investigational use.
STS™ Transmitter installed
STS™ Transmitter Latch
Press
9-hour
3-hour
Glucose Trend Screen
High Glucose Alert Low Glucose Alarm
Low Glucose Alert
CONFIDENTIAL
Under FDA Review
Remove STS™ Transmitter Latch
The antenna should appear here
Error Code
Page 2 of 3
