SMC Networks SMCD3USG Install Manual page 8

Symbol LED
Power
DS
US
Online
Ethernet
WiFi
Tel1
Alarm2
MoCA
Battery
LEDs on
the rear Link
panel
*
: During AC Power Fail with a bad battery, device operation may not be possible due to lack of battery
power; all LEDs may be "OFF".
ON = power is supplied to the Gateway
OFF = power is not supplied to the Gateway
Blinking = scanning for DS channel
ON = ranged on one or more channels
Blinking = ranging is in progress
ON = ranging is complete on 1 channel only
OFF = scanning for DS channel
Blinking = cable interface is acquiring IP, ToD, CM configuration
ON = Gateway is operational
OFF = Gateway is offline
Blinking = data is transmitting
ON = one or more Ethernet link detected
OFF = no Ethernet link detected
Blinking = data is transmitting
ON = Wi-Fi is enabled
OFF = Wi-Fi is disabled
Blinking = phone set off-hook
ON = phone set on-hook
ON = system failure
OFF = normal operation
Blinking = data is transmitting
ON = Gateway is operational
OFF = no Cable/MoCA link detected
Blinking = low battery power
ON = high battery power when AC power failure
OFF = no battery power or no battery when AC power on normal operation*
Blinking = data is transmitting
Green ON = connected at 1 GMbps.
Amber ON = connected at 10 or 100 Mbps
OFF = no Ethernet link detected
