- Page 1 DATASHEET LENZE 6409-01 07/07 CSB7_TAST OTHER SYMBOLS: RGB ELEKTRONIKA AGACIAK CIACIEK SPÓŁKA JAWNA Jana Dlugosza 2-6 Street 51-162 Wrocław www.rgbelektronika.pl Poland biuro@rgbelektronika.pl +48 71 325 15 05 www.rgbautomatyka.pl www.rgbautomatyka.pl www.rgbelektronika.pl...
- Page 2 YOUR PARTNER IN MAINTENANCE Repair this product with RGB ELEKTRONIKA ORDER A DIAGNOSIS LINEAR ENCODERS SYSTEMS INDUSTRIAL COMPUTERS ENCODERS CONTROLS SERVO AMPLIFIERS MOTORS MACHINES OUR SERVICES POWER SUPPLIERS OPERATOR SERVO PANELS DRIVERS At our premises in Wrocław, we have a fully equipped servicing facility. Here we perform all the repair works and test each later sold unit.
-
Page 3: Panel
L−force Controls BA_CS9000DVI .Nsó Operating Instructions Industrial PC Power Fail Power Fail Status Status & § ∗ > < Power Fail Status ∗ Pg Up Power Fail Status Home Einfg Entf Bild Pg Dn Alt Gr Pos 1 Ende Bild Strg Ctrl Menu... - Page 4 Please read these instructions before you start working! Follow the enclosed safety instructions.
-
Page 5: Table Of Contents
Contents About this documentation ..........Document history . - Page 6 ..........7.2.1 Command Station CS 5000 DVI and CS 9000 DVI ....
-
Page 7: About This Documentation
Qualified skilled personnel are persons who have the required qualifications to carry out all activities involved in installing, mounting, commissioning, and operating the product. Tip! Information and auxiliary devices related to the Lenze products can be found in the download area at http://www.Lenze.com... -
Page 8: Conventions Used
About this documentation Conventions used Conventions used This documentation uses the following conventions to distinguish between different types of information: Type of information Identification Examples/notes Spelling of numbers Decimal separator Point In general, the decimal point is used. For instance: 1234.56 Warnings UL warnings Given in English and French... -
Page 9: Notes Used
About this documentation Notes used Notes used The following pictographs and signal words are used in this documentation to indicate dangers and important information: Safety instructions Structure of safety instructions: Danger! (characterises the type and severity of danger) Note (describes the danger and gives information about how to prevent dangerous situations) Pictograph and signal word Meaning... -
Page 10: Safety Instructions
The manufacturer does not accept any liability for the suitability of the specified procedures and circuit proposals. Only qualified skilled personnel are permitted to work with or on Lenze drive and ƒ... - Page 11 Safety instructions General safety information Transport, storage Transport and storage in a dry, low−vibration environment without aggressive ƒ atmosphere; preferably in the packaging provided by the manufacturer. – Protect against dust and shocks. – Comply with climatic conditions according to the technical data. Mechanical installation Install the product according to the regulations of the corresponding ƒ...
-
Page 12: Product−Specific Safety Instructions
Safety instructions Product−specific safety instructions Maintenance and servicing The components are maintenance−free if the required operating conditions are ƒ observed. If the cooling air is polluted, the cooling surfaces may be contaminated or the air ƒ vents may be blocked. Under these operating conditions, the cooling surfaces and air vents must be cleaned at regular intervals. -
Page 13: Safety Instructions For The Installation According To Ul
Safety instructions Safety instructions for the installation according to UL Safety instructions for the installation according to UL Original − English Approval Underwriter Laboratories (UL), UL508 and CSA C22.2 No. 142−M1987, (UL File Number E236341) Ratings Input 24 V DC, max. 65 W (65 VA) ƒ... - Page 14 Safety instructions Safety instructions for the installation according to UL Original − French Homologation Underwriter Laboratories (UL), UL508 et CSA C22.2 n° 142−M1987, (n° de dossier UL E236341) Caractéristiques assignées Entrée 24 V CC, maximum 65 W (65 VA) ƒ Température ambiante maximale : 40 °C ƒ...
-
Page 15: Product Description
After receipt of the delivery, check immediately whether the items match the accompanying papers. We do not accept any liability for deficiencies claimed subsequently. Claim visible transport damage immediately to the forwarder ƒ visible deficiencies/incompleteness immediately to your Lenze ƒ representative. BA_CS9000DVI EN 4.0... -
Page 16: Application As Directed
Product description Application as directed Application as directed The monitor panel is used as intended if it is used solely for providing information in common industrial and commercial areas. Another use or any further use is not permissible. A use that is not intended also includes a use harbouring fatal risks or dangers which, without the provision of exceptionally high safety measures, may result in death, injury or damage to material assets. - Page 17 Product description Device features Overview Command Station CS 5000 DVI / CS 9000 DVI CS 5000 DVI: XGA touchscreen 38.1 cm (15") CS 9000 DVI: SXGA touchscreen 48.3 cm (19") 3 freely assignable function keys Power Fail Status CS57x0−026 Command Station CS 5010 DVI XGA touchscreen 38.1 cm (15")
- Page 18 Product description Device features Command Station CS 5070 DVI XGA touchscreen 38.1 cm (15") 12 freely assignable function keys MF2 keyboard & " § > < Power Fail Status Einfg Entf Bild Alt Gr Pos 1 Ende Bild Strg Ü €...
-
Page 19: Identification
Product description Identification Identification 31855 Aerzen; Germany † Made in Germany ‚ Type ƒ ‡ „ 107AT12345 … ˆ 107AT12345 DVIUSB−012 Type designation ‚ Type code (catalogue/order no.) ƒ Technical data „ Customised material number … Bar code with serial number †... -
Page 20: Controls And Displays
Product description Controls and displays Controls and displays Power Fail Fail USB-A Status USB-B 24 V DC CS50x0−001 Pos. Description Command Station (here CS 5000 DVI) Mounting frame Screen Status LEDs (Power, Fail, Status) Front face control elements Front face USB port (option) Mounting frame connecting plate (option) Nameplate Note! -
Page 21: Options
Product description Options Add−on components Options 3.6.1 Add−on components Operator console CSB 7 Up to 7 freely assignable switching elements that can be used in any combination Emergency−off switch Internal cabling for Command Station with Combicon plug CS57x0−030 Operator console CSB 14 Up to 14 freely assignable switching elements that can be used in any combination Emergency−off switch... - Page 22 Product description Options Add−on components Keyboard CSB MF2 E MF2 keyboard with long−throw keys in stainless steel finish Internal cabling for Command Station with USB Druck Rollen plug ° " § & Einfg Pos. 2 ² 2 ² 3 ³ 3 ³ ß...
-
Page 23: Technical Data
Technical data General data and operating conditions Technical data General data and operating conditions General data Conformity and approval Conformity EN 61000−6−4 EMC Directive Class A, industrial premises EN 61000−6−2 Approbation UL 508 Programmable Controllers (File−No. E236341) CSA C22.2 Other RoHS −... - Page 24 Technical data General data and operating conditions Operating conditions Mounting conditions Mounting place Stand−alone operator console for support arm mounting or direct fixing to a wall, protected against direct solar radiation Ambient conditions Climatic Storage −10 ... +60 °C Transport −10 ...
-
Page 25: Electrical Data
Technical data Electrical data Electrical data Standard device Supply Screen Type Voltage Current at Visible Aspect ratio Resolution Brightness Contrast MTFB 24 V size [V DC] [cm] [pixels] [cd/m CS 5000 DVI CS 5010 DVI 1024 x 38.1 (15") 4 : 3 1 : 550 40,000 CS 5050 DVI... -
Page 26: Mechanical Data
Technical data Mechanical data Mechanical data Standard device Versions and weights Front frame Mounting frame Touchscreen Mass [kg] CS 5000 DVI CS 5010 DVI 10.0 CS 5050 DVI Aluminium Stainless steel Polyester foil CS 5070 DVI CS 9000 DVI 12.0 Without adapter plate and add−on component CS57x0−002 All dimensions in millimetres. - Page 27 Technical data Mechanical data CSB7 CSB14 CSB MF2 E F2 F2 F3 F3 F5 F5 F6 F6 F7 F7 F8 F8 F9 F9 Druck Rollen Rollen ° " § & Pos. Pos. Einfg 2 ² 2 ² 3 ³ 3 ³ ß...
-
Page 28: Mechanical Installation
Mechanical installation Important notes Mechanical installation Important notes The installation must be carried out by qualified, skilled personnel familiar with the applicable national standards. Stop! Sensitive front frame gasket During mounting, the gasket of the front frame is exposed and can be damaged. -
Page 29: Mounting Steps
Mechanical installation Mounting steps Removing the mounting frame Mounting steps 5.2.1 Removing the mounting frame ‚ ƒ „ CS50xx−004 How to proceed: 1. Lay the device flat, with the mounting frame 0 upwards, on a work surface cushioned with a blanket. –... -
Page 30: Fixing The Mounting Frame To The Support Arm
Mechanical installation Mounting steps Fixing the mounting frame to the support arm 5.2.2 Fixing the mounting frame to the support arm Note! Before mounting: Remove mounting frame (¶ 27). ƒ Read documentation of the accessories. ƒ Check whether the mounting location corresponds to the operating ƒ... - Page 31 Mechanical installation Mounting steps Fixing the mounting frame to the support arm With add−on component ‚ ƒ „ … CS57x0−006 How to proceed: 1. Check support arm system for professional mounting and sufficient carrying capacity. – See support arm documentation. 2.
-
Page 32: Fixing The Mounting Frame To The Wall
Mechanical installation Mounting steps Fixing the mounting frame to the wall 5.2.3 Fixing the mounting frame to the wall Note! Before mounting: Remove mounting frame (¶ 27). ƒ Read documentation of the accessories. ƒ Check whether the mounting location corresponds to the operating ƒ... - Page 33 Mechanical installation Mounting steps Fixing the mounting frame to the wall With add−on component ‚ ƒ „ … † ‡ CS57x0−011 How to proceed: 1. Prepare the wall for mounting the wall bracket 0. – The mounting location and the installation material must provide for a permanent mechanical connection.
-
Page 34: Changing The Labelling Of The Operator Console
Mechanical installation Changing the labelling of the operator console Changing the labelling of the operator console The control/display elements on the control desk are factory−labelled according to your specifications. If you require a different labelling, create a new labelling strip according to the following outline. -
Page 35: Electrical Installation
Electrical installation Important notes Electrical installation Important notes The installation must be carried out by qualified, skilled personnel familiar with the applicable national standards. Stop! Sensitive front frame gasket During mounting, the gasket of the front frame is exposed and can be damaged. - Page 36 Electrical installation Important notes Stop! Short circuit and static discharge The device contains components which are endangered in the case of short circuit or static discharge. Possible consequences: The device or parts of it will be destroyed. ƒ Protective measures: Always switch off the voltage supply when working on the device.
-
Page 37: Wiring According To Emc
Electrical installation Wiring according to EMC Wiring according to EMC General notes The electromagnetic compatibility of the system depends on the type and accuracy of the installation. Please especially note the following: – Structure – Shielding – Earthing In the case of a differing installation it is required for evaluating the conformity to the EMC Directive to check the system with regard to compliance with the EMC limit values. -
Page 38: Connecting The Supply And Peripheral Devices
Electrical installation Connecting the supply and peripheral devices Preliminary works Connecting the supply and peripheral devices 6.3.1 Preliminary works For connecting the supply and the peripherals, the screen must be fitted into the mounting frame and hinged down. Stop! Screen may fall down If the screen is not screwed together with the mounting frame it may fall down. -
Page 39: Terminal Diagram Supply
Electrical installation Connecting the supply and peripheral devices Terminal diagram supply 6.3.2 Terminal diagram supply L1 N 0 V PE +24 V CS50x0−021 Mounting frame Screen Power supply unit Note! Observe the max. permissible input voltage. Professionally fuse the device on the input side against voltage variations and voltage peaks. -
Page 40: Dvi Interface
2 m. Otherwise a faultless signal transmission is not guaranteed. Greater distances can be covered with the following Lenze accessories: 2 ... 5 m: "DVI/USB" cable set 5 ... 35 m: DVI/USB extender V4... -
Page 41: Mounting Frame Connecting Plate (Option)
Electrical installation Connecting the supply and peripheral devices Mounting frame connecting plate (option) 6.3.7 Mounting frame connecting plate (option) You can replace the blanking plate in the mounting frame by a connecting plate which serves to connect further interfaces. The following interfaces are available: Description Connection type Cable type... -
Page 42: Assignment Of The Operator Console Connector Board (Only Cs 5010 Dvi)
Electrical installation Assignment of the operator console connector board (only CS 5010 DVI) Assignment of the operator console connector board (only CS 5010 DVI) The adapter board is located within the mounting frame of the Command Station. The scope of supply includes four connector plugs that are plugged on the basic housings of the adapter board in position X1 to X4. -
Page 43: Operation
Operation Important notes Operation Important notes Stop! Sensitive touchscreen surface The touchscreen foil is very sensitive to external forces and can be damaged by improper handling. Possible consequences: The touchscreen foil becomes damaged, scratched or dull. ƒ Protective measures: Avoid contact of the touchscreen foil with pointed or hard objects. ƒ... -
Page 44: Controls And Displays
Operation Controls and displays Command Station CS 5000 DVI and CS 9000 DVI Controls and displays 7.2.1 Command Station CS 5000 DVI and CS 9000 DVI Power Fail Status CS50x0−022 Pos. Designation Function Standard mode Service mode Switch on mode: Press "["... -
Page 45: Command Station Cs 5010 Dvi
Operation Controls and displays Command Station CS 5010 DVI 7.2.2 Command Station CS 5010 DVI Power Fail Status CS50x0−023 Pos. Designation Function Standard mode Service mode Switch on mode: Press "[" for 4 s Switch off mode: Press "[" or wait for 35 s Display Application−dependent Status LEDs... -
Page 46: Command Station Cs 5050 Dvi
Operation Controls and displays Command Station CS 5050 DVI 7.2.3 Command Station CS 5050 DVI Pg Up Power Fail Status Home Pg Dn Ctrl Menu Shift Space Alpha Enter CS50x0−024 Pos. Designation Function Standard mode Alpha mode Service mode Switch on mode: Press "alpha key"... - Page 47 Operation Controls and displays Command Station CS 5070 DVI Pos. Designation Function Standard mode Service mode Switch on mode: Press "[ (F4)" for 4 s Switch off mode: Press "[ (F4)" or wait for 35 s Display Application−dependent Status LEDs Power (green): Is ON when the supply voltage is present.
-
Page 48: Maintenance
Maintenance Regular checks Maintenance Stop! Short circuit and static discharge The device contains components which are endangered in the case of short circuit or static discharge. Possible consequences: The device or parts of it will be destroyed. ƒ Protective measures: Always switch off the voltage supply when working on the device. -
Page 49: Cleaning
Maintenance Cleaning Cleaning Stop! Sensitive surfaces and components The device can be damaged if it is not appropriately cleaned. Possible consequences: The housing or the screen gets scratched or dull if you use alcoholic, ƒ solvent−containing or scouring cleaning agents. Electrical components can be damaged ... -
Page 50: Repair
Maintenance Repair Removing and mounting the screen Repair For the repair of the monitor panel, the screen must be removed and placed flat on a clean, padded work surface. 8.3.1 Removing and mounting the screen Stop! Screen may fall down If the screen is not screwed together with the mounting frame it may fall down. - Page 51 Maintenance Repair Removing and mounting the screen Mounting ‚ max. 12 kg ƒ „ CS50x0−012 Mounting frame Screen Attachment PE connecting cable Other connecting cables BA_CS9000DVI EN 4.0...
-
Page 52: Fuse Change
Maintenance Repair Fuse change 8.3.2 Fuse change Stop! Damage of the device by non−permissible fuse possible The baseboard in the device is protected by a fuse which will be damaged if the supply voltage applied is too high. Possible consequences: The device can be damaged if a non−approved fuse is installed. -
Page 53: Index
Index Index Definition of notes used, 7 Device Adapter board, Assignment, 40 General data, 21 − control/display elements, CSB 7/14, Add−on component Gerät, Bedien− und Anzeigeelemente − dimensions, 25 − CS 5000 DVI, 42 − overview, 18 − version, 24 −... -
Page 54: Panel
Index Mounting conditions, Mounting place, Temperatures, 22 Terminal diagram, 37 Radio interference, 10 Mounting frame, remove, 27 Touchscreen, 23 Regular checks, 46 Mounting steps Type code, 17 Removing the screen, 48 − Change labelling, 32 − finding, 17 Repair, 48 −... - Page 55 © 02/2014 Lenze Automation GmbH Service Lenze Service GmbH Postfach 10 13 52, D−31763 Hameln Breslauer Straße 3, D−32699 Extertal Hans−Lenze−Str. 1, D−31855 Aerzen Germany Germany +49 5154 82−0 008000 2446877 (24 h helpline) Ê Ê +49 5154 82−2800 +49 5154 82−1112 š...
