- Page 1 Satellite Terminal Installation Manual Revision 2.0...
- Page 2 For assistance or additional information about this User Manual, please contact Customer Care Support at: Americas Tel: +1 954 736 8829 Email: support@wideye.com.sg Asia Tel: +65 9820 1820 Email: support@wideye.com.sg Whilst the above information has been prepared by Addvalue Innovation Pte Ltd (“Addvalue”) in good faith, and all reasonable efforts have been made to ensure its accuracy, Addvalue makes no warranty or representation as to the accuracy, completeness, or fitness for purpose or use of the information.
-
Page 3: Table Of Contents
LIST OF CONTENT: CERTIFICATION ____________________________________________________________ 5 SAFETY INSTRUCTIONS _____________________________________________________ 8 IMPORTANT INFORMATION TO INSTALLERS AND USERS _______________________ 10 INMARSAT FLEET ONE COVERAGE __________________________________________ 12 SYSTEM CONFIGURATION __________________________________________________ 13 USER EQUIPMENT LISTS ___________________________________________________ 14 iFleetONE™ USER EQUIPMENT ______________________________________________ 15 Introduction _______________________________________________________ 15... - Page 4 iFleetONE™ Terminal Installation Manual APPENDIX A OUTLINE DRAWINGS ___________________________________________ 37 ADU - Outline Dimensions and Weight _________________________________ 37 ADU - Hole Pattern (Cut-out Holes) ____________________________________ 38 BDU - Outline Dimensions and Weight _________________________________ 39 Optional Primary Handset - Outline Dimensions _________________________ 39 APPENDIX B GPIO PORT ___________________________________________________ 40 Data Connection Switch _____________________________________________ 40 Page 4 of 41...
-
Page 5: Certification
iFleetONE™ Terminal Installation Manual CERTIFICATION FEDERAL COMMUNICATION COMMISSION NOTICE FCC Identifier: QO4-WEFLONEVTWO USE CONDITIONS This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. - Page 6 iFleetONE™ Terminal Installation Manual FCC CAUTION: Any changes or modifications not expressly approved by the manufacturer could void the user’s authority, which is granted by FCC, to operate this iFleetONE™ Maritime Satellite Terminal. Industry Canada Statement: IC: 5023B-WEFLONEVTWO This device complies with Industry Canada’s license-exempt RSSs. Operation is subject to the following two conditions: (1) This device may not cause interference;...
- Page 7 iFleetONE™ Terminal Installation Manual CE RED Declaration of Conformity: The CE RED Declaration of Conformity for the Wideye iFleetONE™ terminal will be added on this page after completing the upgrade process of the CE RED tests. Mobile Earth Stations (MES) 1668 – 1670 MHz is under restricted usage under ECC Decision ECC/DEC/ (04)09 for EU Countries.
-
Page 8: Safety Instructions
iFleetONE™ Terminal Installation Manual SAFETY INSTRUCTIONS For safety and protection, read the manual before attempting to use the iFleetONE™ User Equipment (UE). The following general safety precautions must be observed during all phases of operation, service and repair of this equipment. Failure to comply with these precautions or with specific warnings elsewhere in this user guide violates safety standards of intended use of the UE. - Page 9 To legally operate Inmarsat equipment, it is necessary to obtain permission from the local telecommunications regulatory authorities of the country you are operating from. Using your equipment in any country without permission causes you to run the risk of confiscation of the equipment by the local authorities.
-
Page 10: Important Information To Installers And Users
Contents in this manual are subjected to change without notice and may contain errors or inaccuracies. The manual is periodically revised and updated. To obtain the latest version, please enquire about it from the product manufacturer or distributor. RF Specifications Frequencies of Inmarsat I-4 Transmit: 1626.5 - 1660.6 MHz Receive: 1525.0 - 1559.0 MHz... - Page 11 iFleetONE™ Terminal Installation Manual Warranty Addvalue Innovation Pte Ltd. has made every effort to ensure the correctness and completeness of the material in this document. Addvalue Innovation Pte Ltd shall not be liable for errors contained herein. The information in this document is subject to change without notice.
-
Page 12: Inmarsat Fleet One Coverage
(including 505 emergency call). Roaming outside the Out of Region area will have an impact on the airtime price. A buyer is advised to consult Inmarsat Airtime Providers for specific information regards to airtime prices and specific coverage. -
Page 13: System Configuration
iFleetONE™ Terminal Installation Manual SYSTEM CONFIGURATION iFleetONE™ ADU 15-m Antenna Cable Above Deck Unit (To be installed in an exposed area) Below Deck Unit (To be installed in protected area) Wi-Fi +12V / +24V DC iFleetONE™ Primary Handset AC/DC Power Supply Unit RS232 Serial RJ45... -
Page 14: User Equipment Lists
Terminal Installation Manual USER EQUIPMENT LISTS iFleetONE™ Complete Standard Package Description Order Code Wideye iFleetONE™ BDU FLV2-9TB00-01 Wideye iFleetONE™ ADU with 15-meter Antenna Cable FLV2-0AN00-01 iFleetONE™ Optional Accessories Description Order Code Wideye iFleetONE™ Primary Handset SLF1-0PH00-01 Power Supply 240W AC/DC DIN Rail 24V DC/10A... -
Page 15: Ifleetone™ User Equipment
iFleetONE™ Terminal Installation Manual iFleetONE™ USER EQUIPMENT 1.1 Introduction The iFleetONE™ user equipment (UE) consists of two units: Below Deck Equipment (BDU) which is a communication unit Above Deck Equipment (ADU) which is an antenna unit The wired Primary Handset with a cradle is an optional accessory. 1.2 Above Deck Equipment The ADU is a 3-axis controlled antenna unit which is self-tracking. -
Page 16: Below Deck Equipment
iFleetONE™ Terminal Installation Manual 1.3 Below Deck Equipment The BDU is the heart unit of the iFleetONE™ UE. It has several interface ports and handles all communication links between the ADU, optional Primary Handset and the local communication devices such as analog telephone, computer, network equipment, navigation equipment etc. The BDU requires +12V or +24V DC power supply input. -
Page 17: Installation Of Ifleetone™ Terminal
iFleetONE™ Terminal Installation Manual INSTALLATION OF iFleetONE™ TERMINAL 1.5 Installation of ADU 1.5.1 Overview In general, any obstructing objects like a mast near the antenna unit can block reception or transmission from the satellite’s line of sight. In addition, RF radiation emitting from the antenna will affect the human body. -
Page 18: Interference
The antenna unit must be mounted as far as possible away from the HF antennas, communication/navigations, VSAT systems and any high power radio transmitter (including other Inmarsat-based systems). Radar It is difficult to provide the exact minimum distance between a radar and the antenna unit due to different type of radars in terms of power, radiation pattern and operating frequency band. - Page 19 iFleetONE™ Terminal Installation Manual The table below gives the recommended minimum distance d between X- and S- band radars and the antenna. Antenna damage is normally avoided by ensuring the separation distance is met or exceeded. Antenna location at the minimum distance from Radar (S-Band) Radar Min distance (d) at ±15⁰...
-
Page 20: Obstruction
iFleetONE™ Terminal Installation Manual 1.5.4 Obstruction When locating the antenna, it is very important to ensure that there is a clear line-of-sight to the satellite for all the satellite elevation angles in the region in which the vessel will operate. The antenna moves in azimuth 360⁰... -
Page 21: Antenna Mast
iFleetONE™ Terminal Installation Manual 1.5.5 Antenna Mast The physical size of an antenna mast must be able to support the weight and size of the antenna unit. Additionally, the antenna mast must be able to withstand on-board vibrations and wind speed (up to 100 knots) on the antenna radome. An example of the antenna mounted in a suitable mast is illustrated as below Recommendations of the antenna mast include: ... -
Page 22: Installing The Antenna Unit
iFleetONE™ Terminal Installation Manual Clearance holes for M6 (Recommended >6.5mm) Cut-hole Dimension flange Clearance holes for M6 ( Recommended >6.5mm) In the case of the existing mast’s flange on the vessel or ship does not fit the ADU’s mounting base’s holes, a custom-made mechanical adaptation flange should be designed and fabricated so that the flange acts as an interface between the existing mast and the ADU. -
Page 23: Installation Of The Bdu
Unpack the BDU box. The following items should be checked as to whether they are present: BDU 1 x Ethernet Cable 1 x DC Power Cable 1 x Inmarsat 505 laminated card 1 x Wi-Fi Antenna Hardcopy Quick Start Guide CD ROM (Soft User Manual) ... - Page 24 iFleetONE™ Terminal Installation Manual The BDU comes with a cable support item, which is included in the box. The cable support item is to secure the cables from the BDU. To mount the cable support onto the BDU, Remove the 2 screws of the front mounting bracket ...
- Page 25 iFleetONE™ Terminal Installation Manual Using the holes of mounting brackets and four suitable M4x12mm self-tapping or machined screws so that the BDU is secured to the selected surface. Page 25 of 41...
-
Page 26: Installation Of The Optional Primary Handset
iFleetONE™ Terminal Installation Manual 1.7 Installation of the Optional Primary Handset The primary handset is provided with cradle. It can be mounted on a desktop, bulkhead, top ceiling or under captain’s console similar to the BDU. Separate the primary handset from its cradle so that the cradle can be fixed with the M5 x 12mm self-tapping screws. -
Page 27: Connections
iFleetONE™ Terminal Installation Manual CONNECTIONS Below is the interconnection diagram of the iFleetONE™ Terminal with the cables. 15-meter Antenna Cable (as supplied as standard) Antenna Unit (ADU) 1.5m Ethernet LAN (Category 5) Cable Telephone Cable Computer 1m Handset Cable 1.8m DC Power Cable Earth cable to vessel’s hull Standard... -
Page 28: Bdu's Output Connections
iFleetONE™ Terminal Installation Manual 1.8 BDU’s Output Connections Additional information for the output ports - GPS and GPIO. 1.8.1 GPS Output Connector a GPS output (RS-232 serial) connector for outputting the GPS data in The BDU has NMEA0183 format. RS-232 Output Pinout Pin No. -
Page 29: Gpio Port
iFleetONE™ Terminal Installation Manual 1.8.2 GPIO Port The BDU has a dedicated 10-pin Phoenix connector to provide a GPIO (General Purpose Input/Output) interface to the external devices. I/O Connector Pinout A matching connector is included in the box. NOTE GPIO Port Pinout GPIO Port Pin Signal Name Description of Signal... -
Page 30: Grounding Stud
GETTING STARTED ON THE SYSTEM 1.9 Installing the SIM card The system requires a Fleet One service SIM card to access the Inmarsat network and it is provided by your Airtime Service Provider. Insert the SIM card into the BDU as follows: ... - Page 31 iFleetONE™ Terminal Installation Manual Push the SIM card gently into the slot until it is locked in place. SIM CARD Close the SIM card protective cover. Page 31 of 41...
-
Page 32: Powering Up The System
iFleetONE™ Terminal Installation Manual 1.10 Powering up the system 1.10.1 Switching on the BDU Use the ON/OFF switch on the BDU’s front panel. It normally takes about 1.5 to 3 minutes for the whole terminal to be powered up and to register with the satellite network. Wait for the three LED indicators (“TERMINAL”, “ANTENNA”... -
Page 33: Settings On Web Console
iFleetONE™ Terminal Installation Manual Steady Amber Attempting network registration Blinking Amber Ready for Voice only. Blinking Green Ready for Data only. REGISTERED Steady Green Ready for all (Voice and Data). Steady Network failure / Registration error. No light (Off) No network service. Steady Amber Activating data connection. -
Page 34: Activating A Pdp Context
iFleetONE™ Terminal Installation Manual The Web Console will appear. The terminal will proceed automatically to “Checking PIN status” followed by “Antenna Pointing” and then registering to the network (upon power on). WARNING: If the signal strength is low (< 50 dB), check any obstruction of the antenna unit or the condition of antenna cable. -
Page 35: Deactivating A Pdp Context
iFleetONE™ Terminal Installation Manual 1.11.3 Deactivating a PDP Context To deactivate the PDP context for browsing the internet (or other IP connectivity), click “Deactivate Data Connection”. The BDU LED indicator (“DATA ACTIVE”) will turn off. Page 35 of 41... -
Page 36: Glossary
iFleetONE™ Terminal Installation Manual GLOSSARY Alternating Current Above Decks Unit Access Point Name Below Decks Unit Direct Current File Transfer Protocol Global Position System GPIO General Purpose Input / Output IP Data Internet Protocol Data Network Address Translation Port Address Translation Packet Data Protocol Subscriber Identity Module User Equipment... -
Page 37: Appendix A Outline Drawings
iFleetONE™ Terminal Installation Manual APPENDIX A OUTLINE DRAWINGS ADU - Outline Dimensions and Weight Weight: 3.2 kg. Dimensions are expressed in terms of mm. Page 37 of 41... -
Page 38: Adu - Hole Pattern (Cut-Out Holes)
iFleetONE™ Terminal Installation Manual ADU - Hole Pattern (Cut-out Holes) Dimensions are expressed in terms of mm. Page 38 of 41... -
Page 39: Bdu - Outline Dimensions And Weight
iFleetONE™ Terminal Installation Manual BDU - Outline Dimensions and Weight Weight: 3.1kg Dimensions are expressed in terms of mm. Optional Primary Handset - Outline Dimensions Weight: 430g (including cradle) Dimensions are expressed in terms of mm. Page 39 of 41... -
Page 40: Appendix B Gpio Port
iFleetONE™ Terminal Installation Manual APPENDIX B GPIO PORT Data Connection Switch The data connection switch is used for enabling / disabling the data connection of the Wideye iFleetONE™ terminal. The recommended model and part number of the data connection switch is ACROLECTRIC SWITCH (P/N: C1350XBAAA), which is a non-illuminated rocker switch. - Page 41 iFleetONE™ Terminal Installation Manual 3. Connect the other end of these AWG 24 wires to the GPIO Adaptor’s Pin 1 and 3 respectively. Page 41 of 41...
