Snow Line 560 II, 620 II, 620E II
9
Product overview
(
1 Wheel drive clutch lever
2 Guide handle
3 Auger drive clutch lever
4 Snow discharge chute with protective guard
5 Engine
6 Drive speed selection lever, 5 forward and
2 reverse speeds
7 Hand crank for adjusting snow discharge
chute
8 Shield
9 Auger
10 Height-adjustable skid plates
12 Headlight*
13
14 Snow cleaning tool (attached to shield)
15 Clearing plate
16 Spark plug connector
* Snow Line 620E II only
469186_c
14
16
10
A)
4
8
15
Symbols on the machine
Caution!
Special care required during use.
Read the operating instructions before start-up.
Keep hands out of snow discharge chute.
Switch off engine before working on the
STOP
Wear eye and hearing protection.
of getting entangled.
Disconnect spark plug connector before per-
Models
Typ
560 II
620 II
620E II
1
12
3
6
5
17
10
< - >
GB
2
7
A
M
