OPERATION AND MAINTENANCE
IP800-Series Parts List
1a
2a
3a
9
8
11
12
13
15
14
Blue Housing
4b
1b
2b
3b
Seametrics • 253.872.0284
IP800 Series Parts
4a
1
2
3
6a
4
7a
5
6
5a
7
10a
8
9
10b
10a
10b
11
12
5b 6b
13
14
7b
15
Page 12
IP800-SERIES INSTRUCTIONS
White Housing
1a thru 7a
Upper housing/ Contact service
electronics representative
for your specific
model
Housing gasket/seal 102025
Lower housing Not field
replaceable
Housing screw/washer 100414
kit (4 each)
Plug, steel (battery 100360
units)
Strain relief kit, small 100364
(includes 2)
Strain relief kit, large 101850
(includes 1) (externally
powered units)
Sensor pickup 100508 (Micropower, gray cable,
100419 (Standard, blue cable,
Sensor retaining screw 100298
U-clip, retainer 100154
High pressure retaining 101776
clip (requires 2)
O-ring 100264 (EPDM)
Body See distributor
Bearings (includes 2) 103315
Rotor with shaft 100035 (Kynar®/tungsten carbide)
100036 (Kynar®/ceramic)
100435 (Kynar®/silicone carbide)
Rotor repair kit (#13 & 100317 (Kynar®/tungsten carbide)
#14 above) 100043 (Kynar®/ceramic)
100556 (Kynar®/silicone carbide)
Blue Housing
1b thru 7b
Contact service
representative
for your specific
model
100411
Not field
replaceable
100414
100360
100364
101850
FT450)
FT430/440)
