CONNECTIONS DIAGRAMS

Counter or PLC

Power
Forward Output
(open collector)
Reverse Output
(Option -15 only)
See Dual FT430/440 Diagram for an
example of bidirectional connections.
AO55 4-20 mA Output
+
24 Vdc Power
EX-SERIES
+
Power
_
+
Forward Output
_
+
Reverse Output
(Option-15 only)
–
See Dual FT430/440 Diagram for an
example of bidirectional connections.

FT520 Controller

Pulse
Out
See Dual FT430/440 Diagram for an
example of bidirectional connections.
Seametrics • 253.872.0284
EX-SERIES
+
12 - 24 Vdc
_
+ Max. 6 mA, 30 Vdc
_
Max. 6 mA 30 Vdc
+
_
_
0 0
Frequency
Sensor
+
S
_
FT520
+12V
SEN1
G
SEN2
Page 12
EX100/200 SERIES INSTRUCTIONS
Counter or PLC
Digital Input
AO55
0 0 0 0 0 0
+
_
4-20 mA
_
+
24 Vdc Power
_
+
24 Vdc Power
_
+
4-20 mA
EX-SERIES
+
Power
_
+
Forward Output
_
+
Reverse Output
(Option-15 only)
–
