ENGLISH
Insert both parts of the wing onto the wing connector and connect the plugs of the wing servos.
Use M3x20 countersunk screws to connect the wing with the fuselage.
Make sure that no wires are stuck between the fuselage and the wing.
Turn your transmitter and receiver on. Make sure that the correct model is adjusted on the me-
mory of your transmitter. If possible, try to adjust all rods mechanically.
The next step is to check the running direction and ways of the servos. Therefore please note the
grid below.
Ailerons
Elevator
Rudder
Flaps
The center of gravity is set at 67-72mm behind the leading edge. It is recommended that beginners
set the center of gravity at 67mm. More experienced users can set it further to the back, in order to
achieve a more dynamic flight envelope.
16

INSTALLATION AND TUNING PROCESS

CONTROL THROWS

Normal Thermal
▲ 12 mm
▼ 6 mm, 20% Expo
▲ 10 mm
▼ 8 mm, 25% Expo ▼ 2 mm
◄ 20 mm
► 20 mm
▼ 5 mm

CENTER OF GRAVITY

17
18
20
21
Speed
▲ 1-2 mm
▲ 2 mm
Landing Start/Motor
▼ 4 mm ▼ 2 mm
▼ 15 mm
