9. BINDING THe TeleMeTry-Box To THe
TrANSMITTer
Basically the Telemetry-Box can be connected to R7008SB
and R6308SBT receivers.
To ensure that the Telemetry-Box can pick up data from the
receiver, the receiver must first be bound to the transmitter.
The method of binding is described in the instructions sup-
plied with your transmitter and / or receiver.
Important:
The R6308SBT and R7008SB telemetry receivers only
transmit the telemetry data available to them if the recei-
vers are bound to a FASST / FASSTest transmitter.
The purpose of this is to reduce background electrical in-
terference and unnecessary frequency use of the 2.4 GHz
band.
FASSTest Telemetry Data
FASST steering channels
Telemetry-Box 2.4 GHz FASSTest
BINDING
• Ensure that the receiver in the model is bound to the
RC system transmitter.
• Place the RC system receiver close to the Telemetry-
Box (approx. 10 cm).
• Now switch the Telemetry-Box on.
• Locate the "LINK/MODE" button on the telemetry
receiver and hold it pressed in for about five seconds;
this activates transmit mode on the telemetry receiver.
• The monitor LED on the receiver now flashes red and
green.
• The telemetry receiver is bound by holding the "LINK"
button on the Telemetry-Box pressed in for about three
seconds. The monitor LED flashes red and green.
„LINK"- Taste
Monitor LED
• Now switch off the Telemetry-Box and the receiver in
order to save the binding information.
• When you switch on the receiver and the Telemetry-
Box again, the green LED on the Telemetry-Box lights
up to confirm the link between receiver and Telemetry-
Box.
®
Note:
The Telemetry-Box stores the last two binding processes.
When you switch models, this makes it possible to con-
tinue to use the Telemetry-Box without having to re-bind.
7
