2. GeNerAl DeSCrIPTIoN

Data output is generated via:
• A large, backlit screen
• Sound output via beeper or earphone
• Speech output via loudspeaker or earphone, in
German and English
• Vibration alarm
The device features an internal LiPo battery as power
supply, which is recharged using the USB charge lead
supplied in the set.
The device can be updated by the user himself at any
time via the integral USB port.
The sensor configuration process is carried out using the
S.BUS socket.
The set includes adapters for attaching the Telemetry-
Box to a hand-held or console-type transmitter.
The Telemetry-Box can pick up the signals from any re-
ceiver with integral telemetry transmitter.
For example, from R7008SB and R6308SBT receivers.
The Telemetry-Box is suitable both for upgrading existing
FASST systems to telemetry (R6308SBT required at the
model end), and also as a parallel display and output de-
vice for callers and co-pilots in the case of
FASSTest® telemetry systems.
Telemetry-Box 2.4 GHz FASSTest
3.

SeT CoNTeNTS

1 x Telemetry-Box FASSTest
®
1 x Mounting adapter for hand-held transmitter
1 x Mounting adapter for console transmitter
1 x Mini-USB lead
1 x CD with instructions and driver software
®
4.

SPeCIFICATIoN

Frequency band: ................................ 2.4–2.4835 GHz
Transmission system: .................... FASST/ FASSTest
Channel spacing: .......................................... 2048 kHz
Operating voltage: ................................. 3.7 V (1 LiPo)
Current drain:..................................................... 80 mA
Dimensions: ................................ 92 x 54.5 x 20.5 mm
Weight: ................................................................ 76 g
®
