5. CoNTrolS

The Telemetry-Box features a range of facilities and con-
nection options. These include a set of buttons for con-
trolling the display, and for setting up and programming
sensors.
"eSC" button
- Use this button in programming mode to move
back to the previous menu.
- Briefly pressing the "ESC" button in display mode
activates speech output or the melody, or
switches off the sounds.
- A long press on the "ESC" button in Display mode resets
the Min. and Max. values.
"+" button
- The values are increased or switched on using the "+"
button.
- It is also used to move upwards in
programming mode.
"-" button
- The values are decreased or switched off using the "-"
button.
- It is also used to move downwards in
programming mode.
Special feature of the "+" and "-" buttons:
Holding both these buttons pressed in takes you from the
Display menu to the Programming menu.
"eNT." button
- This button is used to select menus and
activate parameters.
- A long press on this button in the Display menu
takes you to the Volume setting.
4
Telemetry-Box 2.4 GHz FASSTest
"LINK" button
Monitor LED
Mini-USB socket
Earphone socket
®
LCD screen with backlighting
Buzzer / loudspeaker
"ESC" button
"+" button
"-" button
"ENT." button
On / Off switch
S-BUS2 socket
