14.5 MoDel SeleCT MeNu

Data for up to ten different models can be stored in the
"Model Select" menu; they can then be activated when you
wish to fly the corresponding model.
explanation, "Model Select" main menu
Three sub-menus can be selected from the main menu:
• Open model (select model memory)
• New model (create new model memory)
• Erase model (delete model memory)
Use the "-" / "+" buttons or the "ENT." button to select a
sub-menu.
MODEL SELECT
>OPEN MODEL
NEW MODEL
ERASE MODEL
Telemetry-Box 2.4 GHz FASSTest
explanation, "oPeN MoDel" sub-menu
When you open the menu, the screen display looks
like this:
OPEN MODEL EDGE
>EDGE
ARCuS
ASW-28
Now you can select one of the model memories using the
"+" or "-" buttons. Press the "ENT." button to confirm your
choice.
explanation, "New model" sub-menu
When you open the menu, the screen display looks
like this:
NEW MODEL EDGE
+,-./0123456789:
;(=)? ABCDEFGHIJ
kLMNOPQRSTuVWXYZ
-----------------------
MODEL NAME((+ ))
Now you can move the cursor over the letters and symbols
using the "-" button, then accept the desired character
with the "+" button. In this way you can set a name with
up to six characters. Press the "RNT." button to accept the
name. The name is now saved, and is displayed on the
screen at top right.
®
explanation, "erASe model" sub-menu
When you open the menu, the screen display looks
like this:
MODEL ERASE EDGE
>EDGE
ARCuS
ASW-28
Now you can select one of the model memories using the
"+" or "-" buttons. To erase the memory, confirm with the
"ENT." button.
Press the "ESC." button to return to the main menu.
Note:
It is not possible to erase the current memory. If you wish
to erase it, first select a different model memory as the
active memory.
15
