CHIEF PSB-2364 Installation Instructions

Flat panel display mounting bracket

I N S T A L L A T I O N I N S T R U C T I O N S

FLAT PANEL DISPLAY MOUNTING BRACKET

Prior to assembly, unpack carton completely and verify contents.

If you are missing any of the following components, please contact Customer Service at 1-800/582-6480

(1) Interface Bracket

(4) 10-24 x .5 Button Head Cap Screw

(4) M18 OD x 8.3 ID x 20 L Metric Nylon Spacer

(4) .75 OD x .266 ID x .375 L Nylon Spacer

BEFORE PROCEEDING, READ INSTALLATION INSTRUCTIONS COMPLETELY

CAUTION!

WARNING!

PSB-2364

DISPLAYS ARE EXTREMELY FRAGILE.

ALL COMPONENTS MUST BE SECURELY FASTENED TO A

STRUCTURAL MEMBER CAPABLE OF SUPPORTING 4

TIMES THE COMBINED WEIGHT OF ALL COMPONENTS

PLUS THE EQUIPMENT BEING MOUNTED. IF IT CANNOT

SUPPORT THIS WEIGHT, THE STRUCTURE MUST BE

REINFORCED.

THE MAXIMUM WEIGHT TO BE INSTALLED ON THE

MOUNT IS 175 POUNDS (79.38 KG).

Chief Manufacturing, a division of Milestone AV Technologies

8401 Eagle Creek Parkway, Savage, MN 55378

P: 800.582.6480 / 952.894.6280 F: 877.894.6918 / 952.894.6918

Figure 1

(4) Mounting Button – Tapped

(4) M6 x 35mm Phillips Head Screws

(4) M6 x 25mm Phillips Head Screws

(1) 1/8 Allen Key

8804-000362

04/08

Table of Contents

Need help?

Do you have a question about the PSB-2364 and is the answer not in the manual?

Page 1 SUPPORT THIS WEIGHT, THE STRUCTURE MUST BE REINFORCED. THE MAXIMUM WEIGHT TO BE INSTALLED ON THE MOUNT IS 175 POUNDS (79.38 KG). Chief Manufacturing, a division of Milestone AV Technologies 8804-000362 8401 Eagle Creek Parkway, Savage, MN 55378 ©2008 Milestone AV Technologies 04/08 P: 800.582.6480 / 952.894.6280 F: 877.894.6918 / 952.894.6918...
Page 2 With the aid of another person, lift your display up to the Chief Mount, aligning buttons of mounting brackets with slots in the Chief Mount. Lower safety latch on the Chief Mount to secure your display, making sure latch is completely engaged.
