2 CONFIGURATION

After importing the corresponding database in ETS and adding the device into the
topology of the desired project, the configuration process begins by entering the
Parameters tab of the device.

2.1 GENERAL

From the "General" screen it is possible to activate/deactivate all the required
functionality.
ETS PARAMETERISATION
Heartbeat (Periodic Alive Notification) [disabled/enabled]
one-bit object to the project ("[Heartbeat] Object to Send '1'") that will be sent
periodically with value "1" to notify that the device is still working (still alive).
1
The default values of each parameter will be highlighted in blue in this document, as follows:
[default/rest of options].
http://www.zennio.com
Figure 2. General screen
Figure 3. Heartbeat
Technical Support:
HeatingBOX
1
: incorporates a
http://support.zennio.com
7
