Sensors & Software pulseEKKO PRO User Manual page 39

pulseEKKO PRO
1 Run pulseEKKO GPR
A-B Select Data
Folder Number
1 Collect Line Data
A-B Select Line
1 Run
2 Setup Menu
(shortcut)
8 Return
2 Collect Grid Data
A-B X or Y Grid
(if GPR Grid Type is set to XY)
8 Return
3 Collect Data
(No Save)
4 Scope Mode
8 Return
Figure 2-37: Flow chart of the complete pulseEKKO PRO DVL menu system.
2 System Setup
1 GPR Parameters
Antenna Frequency
Time Window
Number
Sampling Interval
Antenna Separation
Antenna Step Size
Radar Velocity
System Stacking
Pulser Setting
2 Acquisition Control
A-B Select X or Y Line
Trigger Method
Number
1 Run
2 Setup Menu (shortcut)
8 Setup Menu
Beeper Activated
Free Run Trace Delay
GPS Parameter
Menu
Odometer Setup Menu
Fibre Optic Testing
3 Survey Parameters
Start Position
Antenna Step Size
Positional Units
Data Directory No.
Survey Type
GPR Grid Type
X Line Spacing
Y Line Spacing
4 Display Parameters
Trace Plotting Type
Gain Type Applied
Gain Applied
5 DVL Setup Menu
1 Set DVL Time &
Date
2 Set DVL Transfer
Mode
3 Set DVl into
Upgrade Mode
4 Select Display Info
Mode
8 Return
6 View Complete
Setup
8 Return
2-System Assembly and Startup
MAIN MENU
3 View Setup 4 File Management
CANBUS
Fibre Optic
DVL Key (B)
Free Run
Odometer
GPS Recording Mode
GPS Transfer Baud Rate
GPS Transfer Parity
GPS Transfer Stop Bits
GPS Transfer Data Bits
GPS Last NMEA String
Test GPS with Listing
Test GPS with Plotting
1 Odometer Calibration
2 Set Calibration Manually
3 Odometer Direction
8 Return
29
5 Shut Down
1 Transfer Directory
A Up
B Down
1 Tag
2 Send
8 Exit
2 Transfer File
1 Next Line
2 Transfer Line
A Prev Directory
B Next Directory
8 Exit
3 Delete Directory
A Up
B Down
1 Tag
2 Delete
8 Exit
4 Delete File
1 Next Line
2 Delete Line
A Prev Directory
B Next Directory
8 Exit
5 View Disk Space
