OPERATION AND MAINTENANCE INSTRUCTIONS
These instructions must remain attached to the ICM Tx Unit or NightFighter Heads-up display system. The end
user only is authorized to remove them from the device. – NFPA 1982 (1998 Edition), par 3.2.3
Read this manual carefully if you have or will have the responsibility for using or servicing the product. These
instructions pertain only to the use of the version of the ICM Tx Unit and NightFighter Heads-up display System
which integrates with the SCBA. These instructions, in addition to the instructions supplied with the SCBA, must
be carefully read and followed by all persons who use or maintain this product. This includes those who have
any responsibility involving its selection or application. The ICM Tx Unit and NightFighter from MSA will per-
form as designed only if used and maintained according to the instructions. Otherwise it could fail to perform
as designed and persons who rely on the SCBA could sustain serious personal injury or death.
Use of this device must be consistent with the requirements of NFPA 1500 Fire Department Occupational Safety
and Health Programs.
The Nightfighter Heads-Up Display System is NIOSH and NFPA certified as an accessory for the Ultra Elite
Facepiece for use with the MSA MMR, Firehawk MMR, and BMR breathing apparatus only.
The warranties made by MSA with respect to the product are voided if the product is not installed, used and ser-
viced in accordance with the instructions in this manual. Please protect yourself and your employees by following
the instructions. Please read and observe the WARNINGS and CAUTIONS inside. For any additional information
relative to use or repair, write or call 1-800-MSA-2222 during regular working hours.
The NightFighter Heads-Up Display System and ICM Tx Unit comply with Part 15 of the FCC Rules. Operation is
subject to the following conditions:
(1) This device may not cause harmful interference and (2) This device must accept any interference that may
cause undesired operation.
Changes and modifications not expressly approved by the manufacturer could void the user's authority to oper-
ate the equipment.
TAL 507 (L) Rev. 1
Tx Unit
© MSA 2005
®
NOTICE
WARNING
Prnt. Spec. 10000005389(A)
Mat. 10058881
Doc. 10000020525

Advertisement

loading
Need help?

Need help?

Do you have a question about the ICM Tx Unit NightFighter and is the answer not in the manual?

Questions and answers

Related Manuals for MSA ICM Tx Unit NightFighter

Summary of Contents for MSA ICM Tx Unit NightFighter

  • Page 1 Facepiece for use with the MSA MMR, Firehawk MMR, and BMR breathing apparatus only. The warranties made by MSA with respect to the product are voided if the product is not installed, used and ser- viced in accordance with the instructions in this manual. Please protect yourself and your employees by following the instructions.

  • Page 2: Table Of Contents

    Receiver, Facepiece Bracket and either NightFighter Use only Duracell MN2400, Energizer E92, or Eveready Transmitter or ICM Tx Unit from MSA. A92 AAA alkaline batteries in the TRANSMITTER. Use of other batteries, or a combination of batteries from 5.
  • Page 3 DESCRIPTION Use only Duracell MN1500 or Energizer E91 AA alka- line batteries in the RECEIVER and ICM Tx. Use of other batteries, or a combination of batteries from dif- ferent manufacturers, will affect the performance of the unit and will void the Intrinsic Safety Approval. Intrinsically-Safe Rating The NightFighter Heads-Up Display System and ICM Tx Unit is certified Intrinsically-Safe in the United States for...
  • Page 4 NOTES TAL 507 (L) Rev. 1 - 10058881...

  • Page 5: System Operations

    NightFighter Receiver and ICM Tx Unit or Nightfighter 1. Turn receiver so the thumbscrew is at the bottom of transmitter, and the Ultra Elite Facepiece. receiver and MSA logo of the receiver is to the right. • The NightFighter Heads-Up Display System Receiver 2.
  • Page 6 NOTES TAL 507 (L) Rev. 1 - 10058881...
  • Page 7 ICM TX UNIT FUNCTIONALITY • The ICM Tx Unit is assembled to the gauge line hose o The top mode button (green) will refresh the receiver and serves as the transmitter for the NightFighter display, set the receiver to continuous mode, and Heads-Up Display System.
  • Page 8 NOTES TAL 507 (L) Rev. 1 - 10058881...

  • Page 9: Using The Icm Tx Unit

    USING THE ICM TX UNIT Note: Refer to chart 2 for the various audible and visual variations in individuals and the protective clothing indicators. worn. Use this alarm as a reference only to increasing time-temperature. Do not use as a substitute for stan- dard operating procedures regarding escape from time-temperature extremes.
  • Page 10 USING THE ICM TX UNIT Chart 3 shows the ICM Tx Unit thermal alarm activation SPECIFICATIONS curve. The time/temperature limits are based on the curve. The thermal alarm sounds if the pre-set limit Chart 4 shows the specifications for the ICM Tx Unit. exceeds the curve.
  • Page 11 USING THE ICM TX UNIT 10. Stand motionless until the pre-alarm sounds. Shake a. 530psig - approximately (2216psi system), unit to reset the alarm. b. 750psig - approximately (3000psi System), 11. If the ICM Tx Unit passes these functional checks, c.
  • Page 12 NOTES TAL 507 (L) Rev. 1 - 10058881...

  • Page 13: During Use

    DURING USE Note: Refer to chart 2 for the various audible and visual WARNING indicators for the ICM Tx Unit. Actual time remaining may be less than the calculated time displayed. Increases in breathing rate may reduce Optional ID Tag (PN 10058545), for use with ICM Tx remaining time more than expected.
  • Page 14 DURING USE Low Battery Warnings ment. A torque of 6 in lbs is suggested. Do not over- tighten the screws. Do NOT use a thread sealant on the screws. WARNING 7. Dispose of, or recycle batteries in accordance with all Replace the batteries in the appropriate device when applicable federal, state, and local regulations.

  • Page 15: Cleaning And Maintenance

    Check for damaged or missing buttons on the unit. 2. Cleaning by wiping with a damp sponge or cloth con- f. Check for any visible signs of damage to compo- taining Confidence Plus Cleaning Solution from MSA. nents. Follow the directions on the Confidence Plus Cleaning g.
  • Page 16 CLEANING AND MAINTENANCE SCBA inspections which are to be performed “After 5. Before replacing the battery cover, be sure that the each use” and “Monthly”. The ICM Tx Unit inspections rubber cover on the ICM Tx Unit is properly engaged must also be performed during these SCBA inspec- with the plastic housing.

  • Page 17: Quick-Fill System Operation

    Standard operating proce- other than those supplied by MSA specifically for the dures should be developed for use of the Quick-Fill Quick-Fill System. Use of any other transfilling hose System, unless using a 3000psi URC Assembly.
  • Page 18 QUICK-FILL SYSTEM OPERATION 2. To attach the Quick-Fill System hose to the SCBA. WARNING a. Remove the rubber dust cap from the male inlet fit- Do not connect a High Pressure SCBA to a secondary ting on the SCBA. Be sure that the cylinder valve is air source with a pressure greater than 4500psig.
  • Page 19 Remove the rubber dust cover from both female fit- authorized to repair or disassemble the Quick-Fill System. tings on the Quick-Fill System hose assembly. If repairs are required, contact your nearest MSA office. c. Remove the rubber dust cover from the male Quick- Call 1-800-MSA-2222.
  • Page 20 NOTES TAL 507 (L) Rev. 1 - 10058881...

  • Page 21: Urc Assembly Operation

    NIOSH approval. Failure to use any transfilling hose assembly or fittings other follow the above warnings may result in serious per- than those supplied by MSA specifically for the URC sonal injury or death. Assembly or Quick-Fill System. Use of any other...
  • Page 22 Rapid Intervention Crews should use a separate air sure air is sealed off. supply such as MSA’s RescueAire™ portable air sup- 5. Immediately install the dust cover on the URC ply system to fill SCBA in a IDLH atmosphere.
  • Page 23 URC Assembly. If b. If you cannot reconnect the hose, reach behind and repairs are required, contact your nearest MSA office. Call close the cylinder valve. Air pressure in the regulator 1-800-MSA-2222.

  • Page 24: Warranty

    PN 10023638 for additional war- ranty information. For a copy of the complete warranty or for information on submitting a warranty claim, write to MSA, Customer Service Department, P.O. Box 426, Pittsburgh, PA 15230-0426 or call 1-800-MSA-2222. For further information or training instructions contact your MSA representative or distributor.
