  • Page 1 INSTALLATION MANUAL TABLE OF CONTENTS Revision 3 2019/02/18 C.A. 213631...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS TABLE OF CONTENTS ............................. 2 CONGRATULATIONS ON THE PURCHASE OF YOUR NEW COVANA COVER..........3 SAFETY ..................................4 Safety information ..............................4 Avoiding the risk of electrocution ..........................5 LABELING ................................. 7 GLOSSARY ................................10 QUICK START-UP INSTRUCTIONS ........................12 Manual lifting procedure ............................13...

  • Page 3: Congratulations On The Purchase Of Your New Covana Cover

    In fact, registering your Covana allows us to quickly reach you in the unlikely event a safety notice was ever to be issued. Your product and safety are a top priority for us at Covana.

  • Page 4: Safety

    Covana cover should only be operated by an The power safety cover meets ASTM F1346-91 adult. requirements.  Covana cover is not to be used by persons DANGER (including children) with reduced physical, sensory  To reduce the risk of injury, do not allow...

  • Page 5: Avoiding The Risk Of Electrocution

     To reduce the risk of electrical shock, replace  Do not roll the Covana cover onto its side or a damaged cord immediately. Failure to do so slide it on its side. This will damage the siding. may result in death or serious personal injury ...
  • Page 6 WARNING REGARDING MODIFICATIONS TO THE COVANA COVER  Any modifications to the Covana cover, such mechanical, electrical aesthetic modifications, may cause the cover to operate in an unwanted or dangerous way. Furthermore, these modifications are not permitted and might void the warranty and certification.

  • Page 7: Labeling

    LABELING WARNING Removing any labels from the Covana cover will void product certification. All labels should always remain visible. It is the owners’ responsibility to ensure these labels are always visible and should never be removed. Risk of electrocution warning, located on the operator unit.
  • Page 8 Key switch warning, located on the key switch. Electrical information, located on the key switch cable. Do not step symbol, located on top of the operator unit. LABELING USER MANUAL...
  • Page 9 Drowning risk warning, found on the inside of the Covana cover. Do not step on cover label, located of end C-Channels of the Covana cover Top label, located on I-Beams and Escape hatch opening Centre label, located on 94 9/16in (240 cm) C-Channel...

  • Page 10: Glossary

    Front frame cut- The front frame cut-out gets installed under the front step of your hot tub. It links the two non-motor-side jacks. Figure 6 Key switch The key switch is used to operate the Covana cover. Figure 7 GLOSSARY USER MANUAL...
  • Page 11 Escape hatch The escape hatch is a removable panel part of the cover. Figure 8 Sleeve The sleeve is an aluminum case for the lifting mechanism. Figure 9 USER MANUAL GLOSSARY...

  • Page 12: Quick Start-Up Instructions

    4) The key must be held in the proper position until fully opened or closed. 5) The Covana cover will automatically stop in both the fully opened and fully closed position. 6) Turn the key clockwise to raise the cover.

  • Page 13: Manual Lifting Procedure

    (Figure 3) Use ½ in. (13 mm) hexagonal socket wrench to raise or lower the Covana cover by turning the operator’s input shaft. (Figure 11) 4) Slowly turn the shaft. Stop immediately if higher Figure 10 tension is felt.

  • Page 14: Using The Escape Hatch

    1) Do not at any point put your weight on the escape hatch as it may hinder the person trapped below. 2) Use the Covana key inside the slot located in the white centre part of the handle. (Figure 12) 3) Turn the handle until the key falls down.

  • Page 15: Winterizing The Evolution Cover

    This can be done by either shutting off and securing the circuit breaker powering the Covana cover; 5) Put a tarp or water-tight protection sheet over the Covana cover. Ensure not to infringe any of the hot tub manufacturers’ guidelines during this step.

  • Page 16: Periodic Maintenance Table

    PERIODIC MAINTENANCE TABLE Your Covana Cover has been designed to provide years of trouble-free enjoyment. As with any appliance, problems may occasionally occur that require the expertise of a certified Covana service technician. Before calling for service, please refer to the Troubleshooting section. Always retain your original sales receipt for future reference.

  • Page 17: Technical Specifications

    TECHNICAL SPECIFICATIONS Side elevation dimensions The maximum distance the Covana cover travels is 52 in. (132 cm). The maximum raised height depends on the height of the hot tub. Add the hot tub height to distance the Covana cover travels to determine the maximum height.

  • Page 18: Frame Dimensions And Foot Print

    Frame dimensions and foot print Standard model **NOT TO SCALE** Figure 16 Cover length 8’ 118’’ (2997 mm) 105¾’’ (2685 mm) 95¼'' (2422 mm) 101½'' (2576 mm) 98'' (2490 mm) 131¼'' (3334 mm) 9’ 130½’’ (3315 mm) 118¼’’ (3004 mm) 107½’’...
  • Page 19 Long side (LS) model (8 feet only) **NOT TO SCALE** Figure 17 USER MANUAL TECHNICAL SPECIFICATIONS...

  • Page 20: Electrical Specifications

    Current draw Max 6 A WARNING  Covana does not allow any modifications of the electrical system. Covana reserves the right to void the warranty if any modifications were done without the specific approval from Covana. Operating limitations WARNING ...

  • Page 21: Troubleshooting

    Wire guard reassembly procedure section in the User manual)  posts  Lower the Covana cover completely and post screws equally positioned. screw the post back in at the correct height. (attached to the outer  Verify whether a drive shaft has fallen off.
  • Page 22  Reassemble the sleeves. cover raises  The chain is broken.  unevenly.  Call your local certified dealer Covana dealer spring for technical support broken.  A drive shaft has fallen off.  The cover raises, but ...

  • Page 23: Warranty

    THREE (3) MONTHS † from the original date of purchase † Please note: The COVANA warranty is deemed effective no later than 12 months following the date on which the unit was shipped from COVANA’s factory in Drummondville, Canada. USER MANUAL WARRANTY...
  • Page 24 PERFORMANCE In the event of a defect covered by this limited warranty, notify your COVANA dealer as soon as possible to obtain service, and use all reasonable means to protect the COVANA Product from further damage. Upon proof of purchase, an authorized dealer will correct the defect subject to the terms and conditions contained in this limited warranty.
  • Page 25 COVANA nor the dealer. COVANA’s only obligation shall be to repair or replace defective parts that do not conform to the warranty. COVANA shall not be liable for any injury, loss or damage, direct or consequential, arising out of the inability to use the Product.

  • Page 26: Appendix

    APPENDIX APPENDIX USER MANUAL...

  • Page 27: Washing The Evolution Cover

    Washing the Evolution cover Cleaning the Evolution is an essential part to maintain and keep your cover in running condition. Clean your cover as needed or when dirt, debris or leaves are present. We also recommend cleaning your cover before and after winterization.

  • Page 28: Post Greasing Procedure

    WARNING  Failure to remove all four top plates will result in important damages to your Covana cover. 5) Turn the key to elevate the system. 6) The four internal jacks will start to elevate but the roof will stay lowered on the spa. (Figure 20)
  • Page 29 8) Spray grease on all the sliding parts and mechanical components for all four jacks. (Figure Figure 21 9) Inspect the posts cables for signs of fraying. If this is the case, please call your local Covana dealer immediately. (Figure 23) Apply grease on four sides 10) Cycle the system up and down and inspect if any of the jack.

  • Page 30: Chain Lubrification Procedure

    An opening allows located the chain. (Figure 27) 4) Using the grease, spray the chain lightly while Figure 26 another person cycles the Covana cover up and down. (Figure 27) 5) Descend the sleeve back into place, ensure the Chain nylon washer is outside of the sleeve.
  • Page 31 USER MANUAL...
  • Page 32 Contact your local dealer for all related service issues. Made in Canada by Covana, a division of the Canimex group. www.covana.com PATENTED CANADA 2,532,429 US 11/162,557 UK 0515168.3 AUSTRALIA 2006200251 The information in this manual was accurate at the time of print. The manufacturer reserves the right to change or improve its product without prior notice.
