Saddle opening receiver power
supply
Horn - Emergency stop warning
light - Instrument panel live supply
- Turn indicator control
Lighter - Helmet compartment light Tripping threchold: 15A
Not used
Immobilizer decoder power supply
- Injection ECU power supply
Injection control unit (+ under key) Tripping threshold: 5A
Stop lights - Coil of the start-up
remote control switch
High-beam light with warning light Threshold of operation: 7.5A
Low-beam light
HV coil - Fuel injector - Fuel pump Tripping threshold: 10A
Locatio: Helmet compartment
Tripping threshold: 4A
Location: Helmet compartment
Threshold of operation: 7.5A
Location: Helmet compartment
Location: Helmet compartment
Tripping threshold: -
Location: Counter-shield
Threshold of operation: 3 A
Location: Shield back plate
Location: Counter-shield
Threshold of operation: 7.5A
Location: Shield back plate
Location: Shield back plate
Threshold of operation: 7.5A
Location: Shield back plate
68
