GILERA WOULD LIKE TO THANK YOU
for choosing one of its products. We have prepared this booklet to help you to get the very best from your scooter. Please read it carefully before riding
the scooter for the first time. It contains information, tips and precautions for using your scooter. It also describes features, details and devices to assure
you that you have made the right choice. We believe that if you follow our suggestions, you will soon get to know your new vehicle and it will serve you
well for a long time to come. This booklet forms an integral part of the scooter; should the scooter be sold, it must be transferred to the new owner.
NEXUS 300 i.e.
Ed. 2

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the NEXUS 300 i.e. and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Gilera NEXUS 300 i.e.

Summary of Contents for Gilera NEXUS 300 i.e.

  • Page 1 GILERA WOULD LIKE TO THANK YOU for choosing one of its products. We have prepared this booklet to help you to get the very best from your scooter. Please read it carefully before riding the scooter for the first time. It contains information, tips and precautions for using your scooter. It also describes features, details and devices to assure you that you have made the right choice.
  • Page 2 The instructions given in this manual are intended to provide a clear, simple guide to using your scooter; this booklet also details routine maintenance procedures and regular checks that should be carried out on the vehicle at an authorised Dealer or Service Centre. The booklet also contains instructions for simple repairs.
  • Page 3 Personal safety Failure to completely observe these instructions will result in serious risk of personal injury. Safeguarding the environment Sections marked with this symbol indicate the correct use of the vehicle to prevent dam- aging the environment. Vehicle intactness The incomplete or non-observance of these regulations leads to the risk of serious damage to the vehicle and sometimes even the invalidity of the guarantee.

  • Page 5: Table Of Contents

    INDEX VEHICLE..................Running in................. 34 Dashboard................Starting up the engine............... 35 Instruments................11 Precautions................36 Indicator unir................11 Difficult start up................. 37 Clock..................12 Stopping the engine..............37 Digital lcd display..............13 Stand..................38 Maintenance icons..............14 Automatic transmission............. 39 Setting the total and trip odometers........
  • Page 6 Rear-view mirrors..............68 Front and rear disc brake............68 Puncture..................70 Periods of inactivity..............71 Cleaning the vehicle..............71 TECHNICAL DATA..............77 Kit equipment................82 SPARE PARTS AND ACCESSORIES........83 Warnings................... 84 PROGRAMMED MAINTENANCE..........87 Scheduled maintenance table........... 88...

  • Page 7: Vehicle

    NEXUS 300 i.e. Chap. 01 Vehicle...
  • Page 8 01_01...

  • Page 9: Dashboard

    Dashboard (01_01) A = Ignition key-switch B = Starter button C = Throttle grip D = Front brake lever E = «Mode» remote switch F = Emergency cut-off switch G= Digital instrument panel H = Warning light unit on digital instrument panel I = Analogue instrument panel L = Passing M = Rear brake lever...
  • Page 10 01_02...

  • Page 11: Instruments

    Instruments (01_02) A = Rpm indicator B = Speedometer with twin scale (km/h and mph) C = Engine control warning light D = Low fuel warning light M = Low oil pressure warning light F = Turn indicator warning light G = Antitheft device LED H = LCD Display I = «Odo/Set»...

  • Page 12: Clock

    B = Headlight warning light C = High-beam warning light D = Warning light pre-installation Clock (01_04) Pressing the button«CLOCK» less than 1 second displays the following sequence: • TIME • DATE • TOTAL/PARTIAL To set the clock push and hold the «CLOCK» button for longer than 3 seconds. The numbers showing the hours will begin flashing.

  • Page 13: Digital Lcd Display

    01_05 Digital lcd display (01_05) A = «SERVICE» maintenance icon B = «BELT» maintenance icon C = Battery Icon D = Miles/gallons icon (Not used) E = 3-digit display F = Fuel gauge...

  • Page 14: Maintenance Icons

    G = Miles per hour icon H = Total odometer indicator I = Partial odometer indicator L = «ODO/SET» button M = Km/h gauge N = «CLOCK» button O = 5-digit display P = «MODE» button Q = Maximum speed indicator R = Mean speed S = Water temperature gauge Maintenance icons (01_06)

  • Page 15: Setting The Total And Trip Odometers

    Setting the total and trip odometers By pressing the button «L» ODO/SET, the display shifts from total to trip odometer. Hold down the button «L» ODO/SET for more than 3 seconds to reset the trip odom- eter, mean speed and maximum speed gauges. Setting the date function (01_07) Set «DATE»...

  • Page 16: Key Switch

    N.B. - MEAN SPEED IS CALCULATED JUST BY TURNING THE KEY TO «ON» AND THE ENGINE HAS TO BE OVER 800 RPM. - TO SHIFT FROM km/h TO mp/h: HOLD DOWN THE «MODE» AND «CLOCK» BUTTONS SIMULTANEOUSLY, WITH THE KEY SET TO «OFF». THEN TURN THE KEY TO «ON»...

  • Page 17: Locking The Steering Wheel

    LOCK «3»: Ignition disabled, extractable key, mechanical antitheft device enabled. SADDLE OPENING«4»: Set this position by pressing the key set to OFF and turning it clockwise. Locking the steering wheel Turn the handlebar to the left as far as it will go, turn the key to position «LOCK» and remove the key.

  • Page 18: Switch Direction Indicators

    Switch direction indicators (01_11) Lever «O» towards «1» = left turn indicators switched on; Lever «O» towards «2» = right turn indicators switched on; The lever «O» automatically goes back to its «0» position and the indicators remain on; push the lever «O» to turn them off. Horn button (01_12) Push the button «P»...

  • Page 19: Start-Up Button

    Start-up button (01_14) To start the engine, pull either one of the two brake levers and press the starter button «B». 01_14 Engine stop button (01_15) The engine can be started when the emergency cut-off switch «F» is set to «1» RUN;...

  • Page 20: Keys

    Keys (01_16, 01_17, 01_18) Two types of keys are supplied together with the vehicle. Key «A» is the «MASTER» key. Only a single copy of this key is supplied, which is necessary to program the codes for all your other keys and for your dealer to perform some maintenance oper- ations.

  • Page 21: Immobilizerdevice Enabled Indicator Led

    Immobilizerdevice enabled indicator led (01_19) Activation of the «PIAGGIO IMMOBILIZER» system is signalled by a flashing «G» warning light. In order to reduce battery discharge, the indicator LED turns off auto- matically after 48 hours of uninterrupted functioning. Should the system fail, different LED flashing patterns will provide the Authorised Service Centre with information on the type of fault detected.

  • Page 22: Programming The Immobilizer System

    VIOLENT SHOCKS MAY AFFECT THE ELECTRONIC COMPONENTS OF THE KEY. IF OWNERSHIP OF THE VEHICLE IS TRANSFERRED, THE RED-HANDGRIP KEY (AS WELL AS THE OTHER KEYS) AND THE "CODE CARD" MUST ALSO BE TRANSFERRED TO THE NEW OWNER. Programming the immobilizer system The procedure for programming the «PIAGGIO IMMOBILIZER»...

  • Page 23: Accessing The Fuel Tank

    WARNING SHOULD THE ENGINE START WITH THE RED KEY (WITH TRANSPONDER OFF), OR IN THE EVENT OF WRONG OPERATION DURING PROGRAMMING, REPEAT THE PROCEDURE FROM THE BEGINNING. Accessing the fuel tank (01_20) To remove the fuel tank cover «A» lift tab «B» and insert the key in lock «C». 01_20 Power supply socket (01_21) There is a plug socket «D»...

  • Page 24: The Saddle

    Electric characteristic Plug socket 12 V - 180 W MAX The saddle (01_22) To lift the saddle and get access to the helmet compartment, insert the key in the key switch «A». With the key set to «OFF», push it and turn it anticlockwise to the «SAD- DLE OPENING»...
  • Page 25 CAUTION BE REMINDED THAT ALTERING IDENTIFICATION REGISTRATION NUMBERS CAN LEAD TO SERIOUS PENAL SANCTIONS (IMPOUNDING OF THE VEHICLE, ETC.). Chassis number To read the chassis number, remove the lid «A» in the helmet compartment. Engine number The engine number «B» is stamped near the rear left shock absorber lower support. 01_23...

  • Page 26: Adjusting The Windscreen

    01_24 Adjusting the windscreen (01_25, 01_26) The windshield can be adjusted to 3 positions «B», «C» and «D» according to the rider's needs. Unscrew the 3 screws «A», remove the windshield upper part and set it in the desired position. Tighten the 3 fixing screws again. WARNING CARRY OUT THIS OPERATION WITH EXTREME CARE SO AS NOT TO 01_25...

  • Page 29: Use

    NEXUS 300 i.e. Chap. 02...

  • Page 30: Checks

    02_01 Checks (02_01) Before using the vehicle, check: 1. That the fuel tank is full. 2. Front and rear brake fluid level 3. That the tyres are properly inflated. 4. The correct functioning of the tail lights, the headlamp, the turn indicators, the stop light and the license plate light.

  • Page 31: Refuelling

    Refuelling (02_02) Reach the fuel tank and unscrew the cap «A». Use premium unleaded petrol, with minimum octane rating of 95. A specific gauge on the instrument panel indicates the fuel level. WARNING 02_02 SWITCH OFF THE ENGINE BEFORE REFUELLING WITH PETROL. PETROL IS HIGHLY INFLAMMABLE.
  • Page 32 show signs of splitting at the sides or irregular tread wear; if this occurs, go to an authorised workshop or at least to a workshop equipped to perform the replacement. CAUTION TYRE PRESSURE SHOULD BE CHECKED WHEN TYRES ARE COLD.INCOR- RECT TYRE PRESSURE CAUSES ABNORMAL TYRE WEAR AND MAKES RID- ING DANGEROUS.

  • Page 33: Shock Absorbers Adjustment

    02_03 Shock absorbers adjustment (02_04, 02_05) The preloading of the springs can be adjusted to 4 positions using the ring nut located in the lower part of the shock absorbers and the specific spanner supplied. Position 1: minimum preload: driver only Position 2 medium preloading: driver only Position 3 medium preloading: rider and passenger Position 4: maximum preloading: driver, passenger, and luggage.

  • Page 34: Running In

    WARNING WE RECOMMEND WEARING GLOVES WHILE CARRYING OUT THIS OPERA- TION IN ORDER TO AVOID INJURIES. WARNING WE STRONGLY RECOMMEND NOT TO ADJUST BOTH SHOCK ABSORBERS WITH DIFFERENT PRELOADING Running in (02_06) WARNING DURING THE FIRST 1000 KM DO NOT RIDE THE VEHICLE OVER 80% OF ITS MAXIMUM SPEED.

  • Page 35: Starting Up The Engine

    Starting up the engine (02_07, 02_08, 02_09, 02_10) The vehicle is fitted with an ignition disabling system controlled by the emergency cut- off switch «F» and the side stand switch. The engine cannot start if the side stand is down or if the RUN/OFF switch is set to OFF If the engine is running, it shuts off when the side stand is lowered or the RUN/OFF switch is pressed when set to OFF.

  • Page 36: Precautions

    CAUTION DO NOT START-UP THE ENGINE IN CLOSED AREAS BECAUSE EXHAUST GASES ARE TOXIC. 02_10 Precautions CAUTION NEVER STRESS THE ENGINE AT LOW TEMPERATURES IN ORDER TO AVOID POSSIBLE DAMAGE. BE CAREFUL NEVER TO EXCEED THE MAXIMUM SPEED WHILE RUNNING DOWNHILL, IN ORDER TO AVOID DAMAGING THE ENGINE. IN ANY CASE, IN ORDER TO PRESERVE THE ENGINE FROM PROLONGED EX- CESSIVE REVOLUTIONS, THE REVOLUTION LIMITER WILL BE ACTIVATED IF THE ENGINE SPEED EXCEEDS THE ESTABLISHED THRESHOLD.

  • Page 37: Difficult Start Up

    WARNING TAMPERING MAY CAUSE SERIOUS ENGINE MALFUNCTION. Difficult start up (02_11) Should there be any problem, proceed as follows: 1. Check that the spark plug is working properly; 2. Check that there is enough fuel in the fuel tank; when there is no more fuel left, refill the tank and start the vehicle by pressing button «B»...

  • Page 38: Stand

    Stand (02_13) CENTRE STAND Push with your foot on the centre stand's fork «F» while lifting the vehicle backward, holding onto the handlebar. SIDE STAND Push with your foot on the fork of the stand "L" to bring it into the open position while lifting the scooter at the same time.

  • Page 39: Automatic Transmission

    Automatic transmission (02_14) To ensure simple, pleasurable riding, the vehicle is equipped with automatic trans- mission with regulator and centrifugal clutch. The system is designed to provide the best performance (acceleration and consumption) while riding on both flat roads and uphill.
  • Page 40 5. Avoid riding off by mounting the scooter when resting on the support. In any case, the rear wheel should not be turning when it comes into contact with the ground, in order to avoid abrupt departures. 6. When riding along roads covered by sand, mud, snow mixed with salt, etc. We advise you to frequently clean the brake disc with a mild detergent to prevent the accumulation of abrasive elements inside the eyelets, leading to premature wear of brake pads.
  • Page 41 CAUTION ANY CHANGES TO THE VEHICLE PERFORMANCE AS WELL AS ALTERATIONS TO ORIGINAL STRUCTURAL PARTS IS STRICTLY FORBIDDEN BY LAW, AND RENDERS THE VEHICLE NO LONGER CONFORMING TO THE APPROVED TYPE AND DANGEROUS FOR RIDING.

  • Page 43: Maintenance

    NEXUS 300 i.e. Chap. 03 Maintenance...

  • Page 44: Engine Oil Level

    Engine oil level In 4-stroke engines, engine oil is used to lubricate the distribution elements, the bush- es and the thermal group. An insufficient quantity of oil can cause serious damage to the engine.In all four-stroke engines, a loss of efficiency in oil performance and consumption should be considered normal.

  • Page 45: Engine Oil Top-Up

    Engine oil top-up Always check oil level before topping-up and add oil without exceeding the MAX level. Getting an oil level between the MIN and MAX levels requires ~ 400 cm³ of oil. Take your vehicle to an Authorised Service Centre to have the engine oil checked and topped-up, if required, as indicated in the scheduled maintenance tables.
  • Page 46 WARNING RUNNING THE ENGINE WITH INSUFFICIENT LUBRICATION OR WITH INADE- QUATE LUBRICANTS ACCELERATES THE WEAR AND TEAR OF THE MOVING PARTS AND CAN CAUSE IRRETRIEVABLE DAMAGE. WARNING EXCESSIVE OIL LEVEL AT TOP-UPS CAN LEAD TO SCALE FORMATION AND VEHICLE MALFUNCTION. CAUTION USED OILS CONTAIN SUBSTANCES HARMFUL TO THE ENVIRONMENT.

  • Page 47: Hub Oil Level

    Hub oil level (03_04, 03_05) Make sure there is oil in the rear hub according to the intervals specified in the sched- uled maintenance table. To check the rear hub oil level, proceed as follows: 1) Rest the vehicle onto its centre stand, on level ground. 2) Unscrew the dipstick «A», dry it with a clean cloth and then reinsert it screwing it fully into place.
  • Page 48 CAUTION AN EXCESSIVE QUANTITY OF OIL CAN LEAD TO SPILL OVER, WHICH MAY CAUSE THE ENGINE AND THE WHEEL TO GET DIRTY. CAUTION WHEN REPLACING THE HUB OIL DO NOT LET THE OIL COME INTO CONTACT WITH THE REAR BRAKE DISC. CAUTION FOR OIL REPLACEMENT, CONTACT ANY AUTHORISED SERVICE CENTRE AS THEY ARE EQUIPPED TO DISPOSE OF USED OILS IN AN ENVIRONMENTALLY...

  • Page 49: Tyres

    Tyres (03_06) Check tyre pressure and wear frequently. Tyres feature wear indicators; replace tyres as soon as these indicators become visi- ble on the tyre tread. Also check that the tyres do not show signs of splitting at the sides or irregular tread wear;...

  • Page 50: Spark Plug Dismantlement

    TYRE INFLATION PRESSURE Front tyre pressure (with 2.3 bar (2.3) passenger) Rear tyre pressure (with 2.3 bar (2.5) passenger) Spark plug dismantlement (03_07, 03_08, 03_09) Proceed as follows: 1. Lift the rubber mat; 2. Remove the right side cover by unscrewing the three screws «A»; 3.

  • Page 51: Removing The Air Filter

    USING NON-COMPLYING ELECTRONIC IGNITIONS OR SPARK PLUGS OTHER THAN THOSE PRESCRIBED MAY SERIOUSLY DAMAGE THE ENGINE. Characteristic Spark plug NGK CR8EKB Electric characteristic Electrode gap 03_09 0.7 ÷ 0.8 mm Locking torques (N*m) Spark plug 12 ÷ 14 Removing the air filter (03_10) Proceed as follows: 1.

  • Page 52: Air Filter Cleaning

    Air filter cleaning (03_11) 1. Wash the sponge with water and neutral soap. 2. Dry it with a clean cloth and small blasts of compressed air. 3. Impregnate the sponge with a mixture of 50% petrol and 50% specified oil. 4.
  • Page 53 a) Place the scooter in a vertical position on the stand. b) Remove the expansion tank cover «A», turning in anticlockwise. c) Look inside the expansion tank: reference «C» shows the adequate coolant level. d) If the coolant level is below reference «C», proceed to top-up when the engine is cold.

  • Page 54: Checking The Brake Oil Level

    Recommended products AGIP PERMANENT SPEZIAL coolant Monoethylene glycol-based antifreeze fluid, CUNA NC 956-16 Checking the brake oil level (03_15) The front and rear brake fluid reservoirs are both positioned on the handlebars. Pro- ceed as follows: 1. Rest the scooter on its centre-stand with the handlebars perfectly horizontal; 2.
  • Page 55 WARNING ONLY USE DOT 4 CLASS BRAKE FLUIDS. COOLING SYSTEM FLUIDS ARE HIGHLY CORROSIVE. MAKE SURE THAT IT DOES NOT COME INTO CONTACT WITH THE PAINTWORK CAUTION AVOID CONTACT OF BRAKE FLUID WITH EYES, SKIN, AND CLOTHING. IN CASE OF CONTACT, RINSE WITH WATER. THE BRAKING CIRCUIT FLUID IS HYGROSCOPIC, THAT IS, IT ABSORBS HUMIDITY FROM THE SURROUNDING AIR.

  • Page 56: Battery

    Battery (03_17, 03_18) To access the battery, proceed as follows: 1. Place the vehicle on its centre stand; 2. Open the saddle following the above instructions, see the «Saddle» section; 3. Remove the piston ring «A» and take out the battery cover. The battery is the electrical device that requires the most frequent inspections.

  • Page 57: Long Periods Of Inactivity

    Long periods of inactivity (03_19) Battery performance will decrease if the vehicle is not used for a long time. This is the result of the natural phenomenon of battery discharging plus residual absorption by vehicle components with constant power consumption. Poor battery performance may also be due to environmental conditions and the cleanness of the poles.
  • Page 58 CAUTION BEFORE REPLACING A BLOWN FUSE, FIND AND SOLVE THE FAILURE THAT CAUSED IT TO BLOW. NEVER TRY TO REPLACE THE FUSE WITH ANY OTHER MATERIAL (E.G., A PIECE OF ELECTRIC WIRE). 03_21 FUSE BOX A Fuse No. 1 Capacity:7.5 A Protected circuits: Injection ECU supply Fuse No.
  • Page 59 Fuse No. 5 Capacity:15A Protected circuits: Lines protected by fuses No. 7 and 8; 180W Socket, Helmet compartment bulb Fuse No. 6 Capacity:30 A Protected circuits:Recharge circuit 03_22 FUSE BOX B Fuse No. 7 Capacity:7.5 A Protected circuits: Digital instrument panel, Turn indicator bulbs, Radiator electric fan remote control, remote...
  • Page 60 Fuse No. 8 Capacity:7.5 A Protected circuits: Digital instrument panel, Antitheft device pre-installation Fuse No. 9 Capacity:7.5 A Protected circuits:Analogue rpm indicator and digital instrument panel, tail lights, instrument panel lights Fuse No. 10 Capacity:7.5 A Protected circuits: Stop bulb, Engine start-up circuit, Horn Fuse No.
  • Page 61 Power: 12V - 55W Quantity: 2 Front headlights bulb Type: Incandescent (W2.1 x 9.5 D) Power: 12V - 5W Quantity: 2 Rear turn indicator bulbs Type: Incandescent (BAU 155 ) Power: 12V-10W Quantity: 2 Front turn indicator bulbs Type: Incandescent (BAU 155 ) Power: 12V-10W Quantity: 2 Tail light and stop light bulb...

  • Page 62: Front Light Group

    Front light group (03_23, 03_24, 03_25, 03_26, 03_27) To access the bulbs, proceed as follows: 1. Remove the Gilera badge with a plain slot screwdriver. 2. Remove the front shield connection unscrewing the two screws «A». 3. Remove the four screws "B".

  • Page 63: Headlight Adjustment

    03_26 03_27 Headlight adjustment (03_28, 03_29) Proceed as follows: 1. Place the vehicle in riding condition and with the tyres correctly inflated on a flat piece of ground at a distance of 10 m from a white screen situated in a shaded area, making sure that the scooter is perpendicular to the screen;...

  • Page 64: Front Direction Indicators

    N.B. THE ABOVE PROCEDURE COMPLIES WITH THE EUROPEAN STANDARDS RE- GARDING MAXIMUM AND MINIMUM HEIGHT OF LIGHT BEAMS. REFER TO THE STATUTORY REGULATIONS IN FORCE IN EVERY COUNTRY WHERE THE ve- hicle IS USED. 03_29 Turn the screw «A» clockwise to lower the light beam, turn the set screw «A» anti- clockwise to raise the light beam.

  • Page 65: Rear Turn Indicators

    03_31 Rear turn indicators (03_32) Undo the screw «A», then remove the glass «B». 03_32...

  • Page 66: Number Plate Light

    Number plate light (03_33) Remove the screw «C», then take out the bulb holder. 03_33 Helmet compartment lighting bulb (03_34) Open the helmet compartment, take out the pressure mounted glass cover «F» and replace the bulb. 03_34...

  • Page 67: Brake Light

    Brake light (03_35, 03_36, 03_37) To remove the Stop Light and Tail Light bulb, proceed as follows: 1. Open the saddle and remove the rear cover by unscrewing the two screws «A» 2. Remove the stop light glass cover unscrewing the four screws «B». 3.

  • Page 68: Rear-View Mirrors

    Rear-view mirrors (03_38, 03_39) To adjust mirrors, loosen the lock nut «A», place the mirror stem adequately and tighten the lock nut. The rear-view mirror is assembled on a stem with a ball 'joint'. The mirror can be adjusted to the desired position manually. 03_38 03_39 Front and rear disc brake (03_40)
  • Page 69 CAUTION THE BRAKING ACTION SHOULD BEGIN AFTER ABOUT 1/3 OF THE BRAKE LEVER STROKE. HAVE THE BRAKE PADS CHECKED BY THE DEALER ACCORDING TO THE CHECKS SPECIFIED IN THE SCHEDULED MAINTENANCE TABLE. HOWEVER, IN THE EVENT OF NOISES COMING FROM THE FRONT AND/OR REAR BRAK- ING SYSTEM DURING OPERATION, IT IS ADVISABLE TO HAVE THE BRAKING SYSTEM CHECKED BY AN AUTHORISED SERVICE CENTRE OR DEALER.

  • Page 70: Puncture

    Puncture (03_41) The vehicle is equipped with Tubeless tyres (without inner tubes). In the event of a puncture, contrary to the situation with a tyre with inner tube, the tyre deflates more slowly, resulting in a greater steering safety. A flat tyre can be repaired with an emer- gency «inflate and repair»...

  • Page 71: Periods Of Inactivity

    Periods of inactivity (03_42) We recommend carrying out the following operations: 1. Clean the scooter thoroughly and then cover it with a canvas; 2. With the engine off and the piston in the bottom dead centre position, remove the spark plug, and pour into its hole 1 t0 2 cc of the recommended oil. Operate the starter button 1-2 times for roughly 1 second to turn the engine over slowly, then insert the spark plug again;...
  • Page 72 CAUTION DETERGENTS CAN POLLUTE WATER. THE VEHICLE MUST BE WASHED AT A WASH STATION EQUIPPED WITH A SPECIAL WATER PURIFICATION SYSTEM. IF YOU WASH THE ENGINE WITH A HIGH-PRESSURE WATER JET MACHINE: • ONLY USE THE FAN JET. • DO NOT PLACE THE WATER JET NOZZLE CLOSER THAN 60 CM. •...
  • Page 73 STARTING FAILURE Emergency switch in «OFF» Set the switch back to «ON» Side stand down Lift stand Fuse blown Replace the blown fuse and have the scooter checked by an Authorised Service Centre. STARTING DIFFICULTIES (SEE SECTION «START-UP PROBLEMS») Lack of fuel in tank. Refuelling Fuel pump fault Contact an Authorised Service...
  • Page 74 IGNITION PROBLEMS Faulty spark plug Contact an Authorised Service Centre LACK OF COMPRESSION Loose spark plug. Screw in the spark plug tightly Cylinder head loose, piston gas Contact an Authorised Service rings worn. Centre Valve stuck Contact an Authorised Service Centre HIGH CONSUMPTION AND LOW PERFORMANCE Air filter blocked or dirty.
  • Page 75 INEFFICIENT SUSPENSIONS Shock absorber fault, oil leak, end Contact an Authorised Service buffer damaged; shock absorber Centre preloading incorrectly set IRREGULAR AUTOMATIC TRANSMISSION Variators and/or transmission belt Contact an Authorised Service damaged Centre STAND DOES NOT RETURN TO POSITION Presence of dirt Clean and grease...

  • Page 77: Technical Data

    NEXUS 300 i.e. Chap. 04 Technical data...
  • Page 78 04_01...
  • Page 79 ENGINE TECHNICAL DATA Type Single-cylinder, 4-stroke Cubic capacity 278 cm³ Bore x Stroke 75x63 mm Compression ratio 11 ± 0.5 : 1 Idle speed 1700 ± 100 rpm Timing system 4 valves, single overhead camshaft, chain-driven. Valve clearance Inlet: 0.10 mm Outlet: 0.15 mm Max.
  • Page 80 Ignition Electronic inductive discharge ignition, high efficiency, with separate HV coil. α/N three-dimensional map Ignition advance managed by control unit Spark plug NGK CR8EKB Fuel supply Electronic injection with electric fuel pump Fuel Unleaded petrol (95 RON) Exhaust muffler absorption-type exhaust muffler with catalytic converter.
  • Page 81 Wheel rim type Light alloy rims. Front rim 15'' x 3.00 Rear rim 14'' x 3.50 Front tyre Tubeless, 120/70 - 15'' 56P Rear tyre Tubeless, 140/60 - 14'' 64P Front tyre pressure (with 2.3 bar (2.3) passenger) Rear tyre pressure (with 2.3 bar (2.5) passenger) Kerb weight...

  • Page 82: Kit Equipment

    04_02 Kit equipment (04_02) • 16 mm box-spanner; • Twin screwdriver; • A pair of pliers to extract fuses. • Wrench for adjusting shock absorbers. The tools are stored in the helmet compartment.

  • Page 83: Spare Parts And Accessories

    NEXUS 300 i.e. Chap. 05 Spare parts and accessories...

  • Page 84: Warnings

    Warnings (05_01) WARNING TO PREVENT ACCIDENTS AND TO GUARANTEE PROPER STABILITY, PER- FORMANCE AND SAFETY, RIDE THE VEHICLE VERY CAREFULLY WHEN IT IS FITTED WITH ACCESSORIES OR WITH UNUSUAL LOADS. WARNING IT IS ALSO RECOMMENDED THAT "ORIGINAL PIAGGIO SPARE PARTS" BE USED, AS THESE ARE THE ONLY ONES OFFERING YOU THE SAME QUALITY GUARANTEE AS THOSE INITIALLY FITTED ON THE SCOOTER.
  • Page 85 WARNING NEVER RIDE THE SCOOTER EQUIPPED WITH ACCESSORIES (TOP BOX AND/ OR WINDSHIELD) AT A SPEED HIGHER THAN 100 km/h. THE SCOOTER CAN BE RIDDEN AT A HIGHER SPEED WITHOUT THE ACCES- SORIES MENTIONED BEFORE WITHIN THE LIMITS ESTABLISHED BY LAW. IF THERE SHOULD BE NON-PIAGGIO ACCESSORIES INSTALLED, OR AN AB- NORMAL LOAD, OR IF THE SCOOTER IS NOT IN A GENERALLY GOOD CON- DITION, OR WHENEVER WEATHER CONDITIONS DEMAND IT, SPEED SHOULD...

  • Page 87: Programmed Maintenance

    NEXUS 300 i.e. Chap. 06 Programmed maintenance...

  • Page 88: Scheduled Maintenance Table

    06_01 Scheduled maintenance table (06_01) Adequate maintenance is fundamental to ensuring long-lasting, optimum operation and performance of your vehicle. For this purpose, PIAGGIO offers a set of checks and maintenance services (for pay- ment), which are included in the summary table shown on the following page. Any minor faults should be reported without delay to an Authorised Service Centre or Dealer without waiting until the next scheduled service to solve it.
  • Page 89 km x 1,000 Driving belt Throttle control Air filter Belt compartment air filter Oil filter Oil filter (mesh) Valve clearance Electrical system and battery Brake fluid * Coolant * Engine oil Hub oil Brake pads Sliding blocks / variable speed rollers Tyre pressure and wear Vehicle road test Suspensions...
  • Page 90 Clean the SAS air filter every 2 years * Replace every 2 years RECOMMENDED PRODUCTS TABLE Product Description Specifications AGIP GEAR 80W-90 Oil for speed gearbox SAE 80W-90, API GL-4 mineral multigrade oil AGIP CITY HI TEC 4T Oil to lubricate flexible transmissions (throttle Oil for 4-stroke engines control) AGIP GP 330...
  • Page 91 TABLE OF CONTENTS Air filter: 51, 52 Fuel: 23 Maintenance: 14, 43, 87, 88 Fuses: 57 Mirrors: 68 Battery: 56 Brake: 54, 67, 68 Headlight: 63 Saddle: 24 Horn: 18 Scheduled maintenance: 88 Hub oil: 47 Shock absorbers: 33 Spark plug: 50 Stand: 38 Clock: 12 Start-up: 19...
  • Page 92 The descriptions and illustrations given in this publication are not binding. While the basic specifications as described and illustrated in this manual remain unchanged, PIAGGIO-GILERA reserves the right, at any time and without being required to update this publication beforehand, to make any changes to components, parts or accessories, which it considers necessary to improve the product or which are required for manufacturing or con- struction reasons.
