Digigram EtherSound ES881v2 User Manual page 21

D i g i g
RING
A ring topology may be opted for to benefit from t
further increase reliability.
the last device is physica
The 'Preferred Clock Source' is designated by the network administrator.
Preferred C lock
Source
•
In case of a cable failure, the first device after this failure automatically switches to Clock Source
operation. The network remains completely functional, there is no audio channel loss.
•
In case of a device failure, the same recovery mechanism applies, but - obviously - audio connected to
the failing device is missing.
STAR
Star is a network topology where all devices are connected to a same unit (a switch in the following picture)
that is handling all the communications.
Switch 1 Switch 1 Switch 1
SWITCH
Device to connect two segments of a Local Area Network. Seeking greater filtering and forwarding speeds,
efforts were made to decrease the amount of time required to determine if a packet should be filtered or
forwarded ('latency') by only examining the address information contained at the start of the Ethernet frame.
The term 'Ethernet Switch' now is used for multiple-port-devices, which are able to filter and forward packets
at nearly the speed of Ethernet ('wire speed') regardless of the technique.
20
r a m
This topology is to be considered an extension of the daisy-chain topology, where
lly connected back to the first.
Clock
Source
Switch 2 Switch 2 Switch 2
he redundancy that this architecture provides and thus to
