- Page 1 REFRIGERATOR & FREEZER LV / RI / RID / RB / FB (Lumavue, Reach-In and Bottom Mount Refrigerator and Freezer ) Installation, Operation and Troubleshooting Manual R290 VERSION Phone: (888) 845-9800 Fax: (800) 253-5168 Website: www.beverageair.com 809-114A Rev B 2017-03-30...
- Page 2 THANK YOU! Thank you for purchasing a Beverage-Air cabinet. This series has passed our strict quality control inspection and meets the high standards set by Beverage-Air Refrigeration! You have made a quality investment that with proper maintenance will give you many years of reliable service! Please read the following installation and maintenance instructions before installing or using your unit.
- Page 3 This inspection includes complete refrigeration system, cabinet construction, and finish IMPORTANT PLEASE RETAIN FOR YOUR RECORDS You may mail this completed page to Beverage-Air Refrigeration or register on line at www.Beverage-Airrefrigeration.com You may mail this completed page to Beverage-Air or register on line at www.beverage-...
- Page 4 A receipted bill from the servicing agency must accompany the claim, together with full details of the service problems, diagnosis and work performed. Beverage-Air will determine at its sole discretion whether further documentation on a claim is to be submitted.
-
Page 5: Table Of Contents
TABLE of CONTENTS 1. Introduction 1.1 Beverage-Air Refrigeration / Freezer 1.2 Glossary of Terms 2 Installation 2.1 Receiving and Inspection 2.2 Uncrating 2.3 Placement 2.4 Set-up A. Roll In B. Reach In 2.5 Leveling, Shelves and Bumper Install 2.6 Cleaning 2.7 Power Supply... -
Page 6: Introduction
Beverage-Air Refrigeration products, refrigerators and freezers, are distinctly designed to accommodate a wide variety of food service needs and situations. Beverage-Air products are designed to keep refrigerated products at 38 F, while frozen products are kept at 0 F for maximum safety and freshness. -
Page 7: Installation
2.1 Receiving and Inspecting Prior to shipping, all Beverage-Air products are factory tested for performance and thoroughly inspected to ensure they are free of any defects. Upon receipt, carefully examine the unit for any damage that may have occurred during shipping and delivery. -
Page 8: Set-Up
INSTALLATION 2.4 Cooler Set-up for Reach In units With Legs or Casters casters WARNING: unit must be blocked and secured prior to installing 1. Legs and casters must be screwed in by hand. Use the threaded holes located on the bottom of the cabinet. - Page 9 INSTALLATION SHELVING ASSEMBLY 809-114A Rev B 2017-03-30...
-
Page 10: Cleaning
INSTALLATION 2.6 Cabinet Cleaning WARNING: DO NOT clean with any product containing bleach or ammonia. Rinse with clean water before drying with clean cloth. Prior to use, the interior and exterior surfaces of the cabinet should be cleaned thoroughly with warm water, mild detergent, and a soft cloth. -
Page 11: Unit Startup
UNIT STARTUP 3.1 Sequence of Operations THE LV, RI, RID, RB & FB MODELS OPERATIONS ARE CONTROLLED THROUGH THE ® USE OF AN ELIWELL NEW 974 CONTROLLER 3.1.1 Refrigerator The refrigerator operates based on the air temperature measured by the probe located at the return air. -
Page 12: Freezer
UNIT STARTUP Condition Cabinet Temp > Setpoint + Deadband ON or OFF Cabinet Temperature <= Sepoint ON or OFF Defrost ON or OFF 3.1.2 Freezer The freezer operates based on the air temperature measured by the probe located at the return air. - Page 13 UNIT START UP CONTROLLER CONTROLLER COMPONENT OPERATION OPERATION ACTION ACTION Compressor turns The Compressor The Compressor Compressor turns off when the air Contact is energized Contact is de-energized on when the air temperature at COMPRESSOR temperature at the probe is equal to or probe is above the (nEW974 - Terminal #4) (nEW974 - Terminal #4)
-
Page 14: Electronic Controller
UNIT STARTUP 3.2 Electronic Controller STAND-BY (ESC) MANUAL DEFROST (FREEZER) SET (ENTER) LIGHT ON/OFF 3.2.1 Control Panel Display Defrost LED Alarm LED On fixed: Automatic defrost active On fixed: ALARM Present Flashing: Manual defrost active Flashing: ALARM Silenced Off: Defrost is off Off: No Alarm Aux LED... -
Page 15: Changing The Setpoint
UNIT START UP 3.2.4 Changing the Setpoint Press and release the button to enter the machine status menu. The screen will display SP Press and release the button again to see the current set point value (see image below). To adjust to a different value press and release the buttons. -
Page 16: Viewing The Current Probe Temperature
UNIT START UP 3.2.5 Viewing the current Probe Temperature Press and release the button to enter the machine status menu. The screen will display SP Use the buttons to change the display to S1 Press and release the button to view the current sensor value. 809-114A Rev B 2017-03-30... -
Page 17: Electronic Controller Parameters
UNIT START UP 3.2.6 Electronic Controller Alarms The alarm condition is always signaled by the alarm icon . To turn off the relative icon will continue flashing. NOTE: If alarm exclusion times are in progress (AL folder of the parameter table), the alarm is not signaled. -
Page 18: How To View Alarms
UNIT START UP 3.2.7 How to View Alarms Press and release the button to enter the machine status menu. The screen will display SP Use the buttons to change the display to AL Press and release the button to view the alarm(s) If more than one alarm is present, use the buttons to scroll through them. -
Page 19: Entering Standby Mode
UNIT START UP 3.2.8 How to Enter the StandBy Mode The Stand By Mode is used to remove power from the condensing unit (Compressor & Condensing Fan) so the coil can be cleaned or the unit defrosted without having to disconnect the power from the unit) In Refrigerator models the Evaporator Fan will continue to run In Freezer models, power is disconnected from the Evaporator Fan, so it does not run. -
Page 20: Preventative Maintenance
PREVENTATIVE MAINTENANCE 4.1 Daily, Exterior 1 - Clean the surface with a sponge and dilute mild detergent. Use a non-abrasive cleaner that does NOT contain chlorine. 2 - Rinse with clean water before drying with clean soft cloth. 3 - Polish with a soft cloth, wiping with the grain of the metal. 4 - Once a week wipe with a film cutting agent or stainless steel polish to maintain finish. -
Page 21: Effectively Cleaning Stainless Steel
PREVENTATIVE MAINTENANCE 4.5 Effective Methods for Cleaning Stainless Steel Cleaning Method of Effective Type of Cleaning Agent Application Finish Soap or ammonia, or Sponge with cloth, then Routine Cleaning Satisfactory for use on all detergent and water. rinse with clear water and finishes. - Page 22 PREVENTATIVE MAINTENANCE 4.5 Effective Methods for Cleaning Stainless Steel Type Cleaning Method of Effective of Cleaning Agent Application Finish Penny-Brite or Copper- Rub with a dry cloth. Brite. Past NuSteel, DuBois Rub with a dry cloth or Use in direction of Temp, or Tarnite.
-
Page 23: Trouble Shooting Chart
TROUBLE SHOOTING 5.1 General WARNING: ALL SERVICING MUST COMPLY WITH STATE AND FEDERAL EGULATIONS SERVICE AND REFRIGERATION SYSTEM CHART ANALYSIS Malfunction Possible Cause Solution Compressor will not start – Line cord not plugged in Plug cord in no hum Compressor starts and runs but unit does not begin to Warm unit to above 60°F prior to initial cool on initial start-up (MT... -
Page 24: Refrigerator Ladder Diagram
TROUBLE SHOOTING 5.2 Refrigerator Ladder Diagram SPE Models Only LEGEND RC – Run Capacitor SC – Start Capacitor OL – Overload - Eliwell Controller Terminal - Connection Point ICR – Control Relay 809-114A Rev B 2017-03-30... -
Page 25: Freezer Ladder Diagram
