Controls Of Projector

1 2
3 4
13
1.
NETVIGATOR
OK
2.
LENS
3.
FOCUS ADJ. Knob
4.
TRAPEZOIDAL ADJ. Knob
5.
POWER on Indicator
6.
DC IN jack
7.
POWER
Bu on
8.
SOURCE
Bu on
S
9.
RETURN
Bu on
10. MENU
Bu on
M
5 6 7 8 9
14
15
16
11. STANDY indicator
Bu ons
12. IR Window ( Rear Side)
13. IR Window ( Front Side)
14. ANGEL ADJ. Knob
15. EAR PHONE Jack
16. AV OUT Jack
17. TF Card Slot ( Micro SD Card )
18. HDMI Port
19. USB Port
20. VGA Port
9
10
11
12
17
18 19
20
