Electrolux GA 55 EEV 200 User Information

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
D
i
s
h
w
a
s
h
e
r
User information
GA 55 EEV 200
g
822 612 744-00-300605-01

Advertisement

Table of Contents
loading

Related Manuals for Electrolux GA 55 EEV 200

Summary of Contents for Electrolux GA 55 EEV 200

  • Page 1 User information GA 55 EEV 200 822 612 744-00-300605-01...
  • Page 2 Dear customer, Please read this User Information carefully and keep it to refer to at a later date. Pass this User Information on to any subsequent owner of the appliance. The following symbols are used in the text: Safety instructions Warning: Notes that concern your personal safety.

  • Page 3: Table Of Contents

    Contents Operating Instructions ............. Safety .

  • Page 4: Operating Instructions

    Operating Instructions Safety Prior to using for the first time • Follow the ”Instructions for installation and con- nection”. Correct use • The dishwasher is only intended for washing do- mestic dishes. • Additions or modifications to the dishwasher are not permitted.

  • Page 5: Diagram Of Appliance

    Diagram of appliance Ceiling spray arm Upper basket spray arm and floor spray arm Filters Dispenser for detergent Dispenser for rinse aid Rating plate Dispenser Programme overview for special salt Control panel ON/OFF button The ON/OFF button is used to turn the dishwasher on and off.
  • Page 6 § Function buttons End of cycle indicator Programme progress display Multi-display Cycle selection button delay timer Halbe Ladung (Half Load) 3in1 function Control indicators Sanitize Spülen + (Extra Rinse) Programme progress display: The current stage of The Programme selection button is used to select the programme is always shown in the programme the desired dishwashing cycle.

  • Page 7: Prior To Using For The First Time

    Prior to using for the first time If you wish to use 3 in 1 detergent: – First read the section “Using 3in1 deter- gents”. – Do not fill up with special salt or rinse aid. If you do not use 3in1 detergent, before using for the first time 1.
  • Page 8 3. Press function button 1. The LED indicator for function button 1 will flash. The multi-display will indicate the hardness setting. 4. Pressing function button 1 increases the hard- ness setting by 1. (Exception: hardness setting 1 follows hardness setting 10). 5.

  • Page 9: Adding Special Salt

    Adding special salt To decalcify the water softener, it must be filled up with special salt. Use only special salt suitable for domestic dishwashers. If you do not use 3 in1 detergent, fill up with special salt: – Before using the dishwasher for the first time. –...

  • Page 10: Filling Up With Rinse Aid

    Filling up with rinse aid With rinse aid the rinsing water drains away better and so you get smear-free, gleaming dishes and clear glasses. If you do not use 3in1 detergent, fill up with rinse aid: – Before using the dishwasher for the first time. –...
  • Page 11 Setting the amount of rinse aid re- quired Only change the amount dispensed, if smears, milky spots (reduce the amount) or dried on water spots (increase the amount) can be seen on glasses and dishes. (See section “If dish- washing results are not satisfactory”.) The dosage can be set from 1-6.

  • Page 12: Activating/Deactivating The Acoustic Signal

    Activating/deactivating the acoustic signal In addition to the optical display (e.g. indicating the end of the cycle, errors) you can also choose to set an acoustic signal. 1. Press the ON/OFF button. If indicators other than the cycle selection but- ton are lit, a dishwashing cycle is activated.

  • Page 13: In Daily Use

    In daily use Loading cutlery and dishes Sponges, cleaning cloths and any other ob- jects that can absorb water must not be washed in the dishwasher. Plastic and Teflon- coated dishes and pans tend to retain water droplets. These dishes and pans therefore do not dry as well as those made of china and stainless steel.
  • Page 14 Loading cutlery Warning: Sharp knives and other items of cut- lery with sharp edges must be laid in the cut- lery rack or in the upper basket to avoid the risk of injury. To ensure that all items of cutlery in the cutlery bas- ket can be reached by the water, you should: 1.
  • Page 15 Pots, Pans, Large Plates Load large and heavily soiled dishes in the lower basket. The plate rack running right to left at the front right- hand side is most suitable for small flat plates with a diameter of 170-210 mm. A serving plate can be placed in front of the cutlery basket.
  • Page 16 Cups, Glasses, Coffee Service Load smaller, fragile crockery and long, sharp cutlery in the upper basket. Adjustable cup racks • Arrange items of crockery on and under the folding cup racks so that they are offset from each other and water can reach all items. •...

  • Page 17: Adjusting The Height Of The Upper Basket

    Adjusting the height of the upper basket Maximum height of dishes in the Upper basket Lower basket with upper basket raised 19 cm 32 cm with upper basket lowered 21 cm 30 cm The height of the baskets can also be adjusted when they are loaded.

  • Page 18: Adding Detergent

    Adding detergent Detergents remove the dirt from dishes and cutlery. The detergent must be added before the cycle starts. Only use detergent intended for domestic dishwashers. The detergent compartment is located on the inside of the door. 1. If the lid is closed: Press the release button.
  • Page 19 Concentrated detergents Today’s detergents for dishwashers are almost ex- clusively low-alkaline concentrated detergents with natural enzymes in tablet or powder form. Using 50°C dishwashing cycles in conjunction with these concentrated detergents reduces pollution and is good for your dishes, as these dishwashing cycles are specially matched to the dirt-dissolving properties of the enzymes in concentrated detergents.

  • Page 20: Using 3In1 Detergents

    Using 3in1 detergents These products are detergents with a combined cleaning, rinsing and salt function. When the 3in1 function is activated, – the addition of special salt and rinse aid from the respective dispenser is prevented. – If the salt and rinse aid dispensers are empty, this is not indicated.

  • Page 21: Selecting The Dishwashing Cycle (Cycle Table)

    Selecting the dishwashing cycle (Cycle Table) Programme Consumption sequence values Dishwashing- Suitable Type of cycle for: soiling Auto Dinner service and normally soiled, (50° - 65°) • • • • cookware dried-on food remains Gläser (Glass) Dessert dishes and (45°) coffee service, deli- lightly soiled •...
  • Page 22 Selecting a programme When your dishes look like this, select: an intensive programme. a normal or energy-saving programme. a short programme (e.g. 30 minute programme).

  • Page 23: Starting A Dishwashing Cycle

    Starting a dishwashing Additional functions cycle Halbe Ladung (Half Load) Can be selected with the cycles: INTENSIVO, NOR- 1. Check that the spray arms can turn freely. Select this additional function when there are only 2. Turn the water tap on fully. half the number of dishes.

  • Page 24: Setting The Delay Timer

    Setting the Delay Timer Removing the dishes It is normal for the inner door and the dispens- With the delay timer you can delay the start of ers to be damp. a dishwashing cycle for between 1 and 19 • Empty the lower basket first, then the upper bas- hours.

  • Page 25: Care And Cleaning

    Care and cleaning Do not use furniture care products or aggres- sive cleaners. • When necessary, clean the dishwasher’s controls with a soft cloth and clean warm water. • Occasionally check the internal dispensers, door seal and water inlet filter (if fitted) for dirt and clean them, if necessary.
  • Page 26 Fine filter (2) The fine filter must be cleaned occasionally. 1. Open the door and remove the lower basket. 2. Release the fine filter by turning to the right and re- move. 3. Clean the fine filter thoroughly with a brush under running water.
  • Page 27 Middle spray arm 1. Remove the middle spray arm by turning it lateral- The two-part spray arm bearing is held together by a tension spring (B) 2. Clean spray arm nozzles. 3. To re-fit, press the middle spray arm upwards until you feel it snap into place.

  • Page 28: What To Do If

    What to do if... Remedying small malfunc- tions If one of the following fault codes is displayed in the multi-display during operation: – Fault codeÅ 10 (Problems with water inlet), – Fault codeÅ 20 (Problems with water drainage), please have a look at the following table. When the fault is remedied, press the cycle selection button.

  • Page 29: If The Dishwashing Results Are Not Satisfactory

    Malfunction Possible cause Remedy Contact customer service and in- form them of the fault code. If no code is displayed, call up the code from the fault memory: When the appliance is switched off, press and hold function buttons 1 Cycle is performed to the end and 3.

  • Page 30: Disposal

    Disposal Packaging material The packaging materials are environmentally friendly and can be recycled. The plastic com- ponents are identified by markings, e.g. >PE<, >PS<, etc. Please dispose of the packaging materials in the appropriate container at the community waste disposal facilities. Old appliance The symbol on the product or on its pack-...

  • Page 31: Technical Data

    Technical data Capacity: 11 place settings including serving dishes Permitted water pressure: 1-10 bar (=10-100 N/cm = 0.1-1.0 MPa) Electrical connection: 230 V, 10 A, also see the rating plate on the right-hand side of the dishwash- er’s interior door. Total output 2250 W Dishwashers that can be integrated and built-in...

  • Page 32: Notes For Test Institutes

    Notes for Test Institutes Testing in accordance with EN 60704 must be car- ried out with the appliance fully loaded and using the test cycle (see "Cycle Table"). Tests in accordance with EN 50242 must be car- ried out when the salt dispenser in the water softener and the rinse aid dispenser have been filled with salt and rinse aid respectively, and using the test cycle (see "Cycle Table").

  • Page 33: Installation And Connection Instructions

    Installation and connection instructions Safety information for the installation • Only transport the dishwasher in an upright posi- tion, otherwise salt water may run out. • Before using the dishwasher for the first time, check for any damage caused in transport. Do not under any circumstances connect an appliance that is damaged.

  • Page 34: General

    General • The dishwasher is supplied ready to be connected to the electrical supply, i.e. with electrical cable, in- stalled drain hose and inlet hose with filter. • The dishwasher may be built into recesses made of flammable materials without additional meas- ures being taken.

  • Page 35: Building In

    Building in 1. Stand the machine in front of the kitchen unit. Place cable and hoses into the neighbouring unit. 2. Push the machine in, pull the cable and hoses through and ensure that they do not become kinked. 3. Line up the dishwasher and fix it on both sides in the upper area of the tub casing.

  • Page 36: Electrical Connection

    Electrical connection Installation must be via a supply with a plug. The plug must be accessible after the installation, or a separation device with at least a 3 mm contact gap must be provided in the permanent house wiring that gives the appliance simultaneous all-pole separation from the electrical supply in accordance with NIN 2000.

  • Page 37: Servicestellen

    Servicestellen Demonstration / Vente 5506 Mägenwil/Zürich 8048 Zürich Industriestr. 10 Badenerstrase 587 044 405 81 11 9000 St. Gallen Vonwilstrasse 15 Garantie 4127 Birsfelden Nous octroyons sur chaque produit 2 ans de garan- Hauptstrasse 52 tie à partir de la date de livraison ou de la mise en service au consommateur (documenté...

  • Page 38: Garanzia

    Pièces détachées, accessoires et produits d'entretien Pour la Suisse : Vous pouvez commander des pièces détachées, des accessoires et des produits d'entret- ien en ligne sur http://www.electrolux.ch Ricambi, accessori e prodotti di pulizia Per la Svizzera: Ricambi, accessori e prodotti di pulizia si possono ordinare direttamente sul sito in- ternet http://www.electrolux.ch...

  • Page 39: Service

    Service In the event of technical faults, please first check whether you can remedy the problem yourself with the help of the operating instructions (section “What to do if…”). If you were not able to remedy the problem yourself, please contact the Customer Care Department or one of our service partners.
  • Page 40 The Electrolux Group. The world´s No.1 choice. The Electrolux Group is the world´s largest producer of powered appliances for kitchen, cleaning and outdoor use. More than 55 million Electrolux Group products (such as refrigerators, cookers, washing machines, vacuum cleaners, chain saws and lawn mowers) are sold each year to a value of approx. USD 14 billion in more...
