- Page 1 Operator’s Manual Second Edition Third Printing with Maintenance Information Part No. 82233...
-
Page 2: Table Of Contents
Only trained and authorized personnel shall be permitted to operate this machine. This manual should be considered a permanent part of your machine and should remain with the machine at all times. If you have any questions, please call Genie Industries. Contents Page Safety ................ - Page 3 You read, understand and obey: Manufacturer's instructions and safety rules—safety and operator's manuals and machine decals employer's safety rules and worksite regulations applicable governmental regulations You are properly trained to safely operate the machine. Part No. 82233 Genie GS-2668 RT & Genie GS-3268 RT...
-
Page 4: Safety
300 lbs / 136 kg 700 lbs / 318 kg Do not operate the machine during lightning or storms. Do not use the machine as a ground for welding. Genie GS-2668 RT & Genie GS-3268 RT Part No. 82233... - Page 5 All personnel must be removed from the platform before attempting to free the platform using the ground controls. Part No. 82233 Genie GS-2668 RT & Genie GS-3268 RT...
- Page 6 Do not place loads outside the platform perimeter. or guard rail system can increase the weight in the platform and the surface area of the platform or the load. Genie GS-2668 RT & Genie GS-3268 RT Part No. 82233...
- Page 7 Do not operate the machine unless the guard rails are properly installed and the entry is secured for Observe and use color-coded direction arrows on operation. the platform controls and platform decal plate for drive and steer functions. Part No. 82233 Genie GS-2668 RT & Genie GS-3268 RT...
- Page 8 Limit travel speed according to the condition of the ground surface, congestion, slope, location of Be sure all maintenance has been performed as personnel and any other factors which may cause specified in this manual and the appropriate Genie collision. service manual. Component Damage Hazards Be sure all decals are in place and legible.
- Page 9 Yellow without safety alert symbol—used to indicate the presence of a potentially hazardous situation which, if not avoided, may result in property damage. Green—used to indicate operation or maintenance information. Part No. 82233 Genie GS-2668 RT & Genie GS-3268 RT...
-
Page 10: Legend
8 Outrigger housing (if equipped 17 Ground controls with manual with outriggers) lowering valve and LED diagnostic readout 9 Outrigger footpad (if equipped with outriggers) 18 Ground controls side cover Genie GS-2668 RT & Genie GS-3268 RT Part No. 82233... -
Page 11: Controls
Low speed operation for models) inclines 13 Thumb rocker switch for steer function 20 LPG operation button with 7 Generator select switch with indicator light (Gasoline/LPG indicator light 14 Error indicator light models) Part No. 82233 Genie GS-2668 RT & Genie GS-3268 RT... - Page 12 Glow plug button (option - Diesel models) selection Fuel select switch (Gasoline/LPG models) Function enable button LED diagnostic readout Platform up button 20 amp circuit breaker for controls circuit Hour meter Genie GS-2668 RT & Genie GS-3268 RT Part No. 82233...
- Page 13 16 Error indicator light switch button: Low speed operation button 17 Power light operation for with indicator light 18 Function enable/high inclines (Gasoline/LPG speed select button models) for up/down function Part No. 82233 Genie GS-2668 RT & Genie GS-3268 RT...
-
Page 14: Pre-Operation Inspection
Scheduled maintenance inspections shall be performed by qualified service technicians, according to the manufacturer's specifications and the requirements listed in the responsibilities manual. Genie GS-2668 RT & Genie GS-3268 RT Part No. 82233... - Page 15 Hydraulic hoses, fittings, cylinders and manifolds Fuel and hydraulic tanks Drive motors Wear pads Tires and wheels Engine and related components Limit switches, alarms and horn Nuts, bolts and other fasteners Part No. 82233 Genie GS-2668 RT & Genie GS-3268 RT...
-
Page 16: Maintenance
Indicates that tools will be required to perform this procedure. Indicates that new parts will be required to perform this procedure. Indicates that a cold engine is required before performing this procedure. Genie GS-2668 RT & Genie GS-3268 RT Part No. 82233... - Page 17 Do not overfill. 6 Install the vent caps. Adding terminal protectors and a corrosion preventative sealant will help eliminate corrosion on the battery terminals and cables. Part No. 82233 Genie GS-2668 RT & Genie GS-3268 RT...
- Page 18 Result: The fluid level should be in the range. NORMAL Bodily injury hazard. Fluids in the radiator are under pressure and extremely hot. Use caution when removing cap and adding fluids. Genie GS-2668 RT & Genie GS-3268 RT Part No. 82233...
-
Page 19: Function Tests
Result: No function should operate. technician, according to the manufacturer's specifications. After repairs are completed, the operator must perform a pre-operation inspection and function tests again before putting the machine into service. Part No. 82233 Genie GS-2668 RT & Genie GS-3268 RT... - Page 20 Result: The green power light should come on. Result: The steer wheels should turn in the direction that the blue triangle points on the control panel. Genie GS-2668 RT & Genie GS-3268 RT Part No. 82233...
- Page 21 34 Slowly move the control handle to the full drive position. Result: The maximum achievable drive speed with the platform raised should not exceed 0.73 feet / 0.22 meters per second. Part No. 82233 Genie GS-2668 RT & Genie GS-3268 RT...
-
Page 22: Workplace Inspection
It is the operator's responsibility to read and remember the workplace hazards, then watch for and avoid them while moving, setting up and operating the machine. Genie GS-2668 RT & Genie GS-3268 RT Part No. 82233... -
Page 23: Operating Instructions
That means every new operator should perform a pre-operation inspection, function tests, and a workplace inspection before using the machine. Part No. 82233 Genie GS-2668 RT & Genie GS-3268 RT... - Page 24 Machine travel speed is restricted when the platform is raised. Drive Select Button Machine on incline symbol: Low range operation for inclines Genie GS-2668 RT & Genie GS-3268 RT Part No. 82233...
- Page 25 Controller 4 Chock the wheels. Maintain safe distances between the operator, the machine and fixed objects. Be aware of the direction the machine will travel when using the controller. Part No. 82233 Genie GS-2668 RT & Genie GS-3268 RT...
- Page 26 Positioning machine on a slope When setting the machine up on a slope, the steer- end outriggers must be lowered first. Genie GS-2668 RT & Genie GS-3268 RT Part No. 82233...
-
Page 27: Transport Instructions
2 Turn the brake release knob clockwise to reset loaded. the brakes. Towing the Genie GS-2668 RT or the Be sure the vehicle capacity, loading surfaces GS-3268 RT is not recommended. If the machine and chains or straps are sufficient to withstand must be towed, do not exceed 2 mph / 3.2 km/h. -
Page 28: Decals
GS-2668 RT & DC 82236 Notice - Operating Instructions - Ground 52070 Notice - Tire Specifications 82239 Label - Latch 52071 Notice - Kubota Gas Engine Specs 82366 Label - Chevron Rykon Genie GS-2668 RT & Genie GS-3268 RT Part No. 82233... - Page 29 Second Edition · Third Printing Operator's Manual DECALS Additional decals for models with outriggers Engine Side Shading Ground Controls indicates decal Side is hidden from view, i.e. under covers Part No. 82233 Genie GS-2668 RT & Genie GS-3268 RT...
-
Page 30: Specifications
(A-weighted) It should be used only with adequate safety factors. Continuous improvement of our products is a Genie policy. Product specifications are subject to change without notice or obligation. Genie GS-2668 RT & Genie GS-3268 RT... - Page 31 Maximum sound level at normal operating workstations does not incorporate different option configurations. (A-weighted) It should be used only with adequate safety factors. Continuous improvement of our products is a Genie policy. Product specifications are subject to change without notice or obligation. Part No. 82233...
- Page 32 Genie North America Phone 425.881.1800 Toll Free USA and Canada 800.536.1800 425.883.3475 Genie Holland Genie Australia Pty Ltd. Phone + Phone + 31 70 51 78836 61 7 3375 1660 Fax + Fax + 31 70 51 13993 61 7 3375 1002...
