Instrument and control functions

Multi-function meter unit

5 6 7
4
4 3 2 1
1. "RESET" button
2. "SELECT" button
3. Clock
4. Coolant temperature meter
5. Transmission gear display
6. Tachometer
7. Speedometer
8. Shift timing indicator light
9. Fuel meter
10.Multi-function display
WARNING
Be sure to stop the vehicle before
making any setting changes to the
multi-function meter unit. Changing
settings while riding can distract the
EAUN1431
operator and increase the risk of an
accident.
8 9 1 0
The multi-function
equipped with the following:
a speedometer
MPH
a tachometer
MPG mile
a clock
a fuel meter
a coolant temperature meter
a transmission gear display
a multi-function display
a shift timing indicator light
a self-diagnosis device
TIP
Be sure to turn the key to "
fore using the "SELECT" and "RE-
SET" buttons, except for setting
the shift timing indicator light con-
trol mode.
EWA12423
To switch the speedometer and
multi-function displays between
kilometers and miles, press the
"SELECT" button for at least one
second.
Speedometer
The speedometer shows the vehicle's
traveling speed.
Tachometer
meter unit is
1. Tachometer
2. Tachometer red zone
The tachometer allows the rider to
" be-
monitor the engine speed and keep it
within the ideal power range.
When the key is turned to "
chometer will sweep across the r/min
range and then return to zero r/min in
order to test the electrical circuit.
NOTICE
Do not operate the engine in the ta-
chometer red zone.
Red zone: 14000 r/min and above
4-4
1 2
MPH
MPG mile
", the ta-
ECA10032
