14.3 Deck Replacement

To replace the deck, follow these steps:
1. Set the new deck in place and start the four mounting screws to hold the
deck in place while reassembling the EXB-8200. Do not tighten these
screws at this time.
2. Mount the door assembly from the old deck on the new deck (see Sec-
tion 13).
3. Install the faceplate on the main housing (see Section 12).
4. Close the door to the deck and position the deck so that the door is flush
with the faceplate.
5. Tighten the deck mounting screws to 1.7 inch-pounds of torque.
Do not overtighten the screws. Overtightening these screws can
strip the screw holes in the new deck.

14.4 Reassemble the EXB-8200

To reassemble the EXB-8200, replace these parts in the following order:
SV card
SV card cover
DB/DS/DR card
MX card
DF card
CD card
RW card
Deck hanger
Card retainers
Top cover
May 1990
14 Deck Assembly Removal and Replacement
CAUTION
Section 9
Section 5
Section 8
Section 8
Section 8
Section 8
Section 8
Section 7
Section 6
Section 4
