FLIR Digimerge DNR200V Series Quick Connection Manual

PACKAGE CONTENTS:

Network Video Recorder (NVR) USB mouse
Remote control Power adapter (x2)
Ethernet cable
Quick Start Guides
CD
(includes software & manual)
For s up p or t, v is it
ww w.di gi merge.c o m
w ww.f lir.co m/secu rity
Information in this document is subject to change without
notice. As our products are subject to continuous improvement,
Digimerge Technologies Inc., a FLIR company, and our subsidiaries
reserve the right to modify product design, specifications and
prices, without notice and without incurring any obligation.
E&OE © 2013 FLIR / DIGIMERGE. All rights reserved.
Quick Connection Guide

Connecting your system

1 2
Power
IP Cameras*
(to PoE Ports)
Ethernet Extension Cable*
NOTE: It may take up to
1 minute for cameras to start up
and transmit video to your NVR.
Connect cameras
1~4 to NVR
OR
Connect cameras to a Router* or
Switch* on your LAN. If your NVR has
more than 4 channels, this is required
to connect channels 5 and higher**
*Not included/sold separately.
**See reverse to add cameras from your LAN; 8-port PoE switch
accessory sold separately (model: ACCDPS281).
DNR200V Series
Network Video Surveillance Recorder
3 4
Mouse Monitor/TV*
7: ON
5 6
Power
Router*
(to NVR)
OR
HDMI VGA*
DNR200V Series Quick Connection Guide - English - R2
