SECTION 7
[CHASSIS PARTS]
REF. ORDER
NO. NO.
J1 6510004880 Connector MR-DS-E 01
MP1 8010019000 1705 chassis (B)-1
Screw PH BT M3 × 8 NI-ZU
MP2 8810008660
Screw PH BT M3 × 8 NI-ZU
MP3 8810008660
Screw PH BT M3 × 8 NI-ZU
MP4 8810008660
Screw PH BT M3 × 12 ZK
MP5 8810009370
MP6 8930027480 1126 TR-A clip
MP7 8820000870 1705 cap screw
MP8 8110006941 1705 cover (B)-1
MP11 8930039611 Thermally sheet (C)-1
MP15 8930039630 1706 jack sheet
MP16 8930036771 1705 main seal-1
MP17 8930056200 Shield tape (K)
MP18 8930056000 Shield tape (I)
MP20 8930037760 Insulation plate
[FRONT UNIT]
REF. ORDER
NO. NO.
R26 7210002830 EVU-F2JFK4 B14
J1 6450001470 Connector 95003-2881
DS1 5030002180 LCD TSC0712-UFTDHW
EP2 8930048320 LCD contact SRCN-2140-SP-N-W
MP1 8210015740 2140 front panel assembly
MP2 8930047980 2140 LCD holder
MP3 8930048290 2140 LCD filter
MP4 8210015770 2140 reflector
MP5 8930059320 2140 front key (B)
8930047860 2140 front key
MP7 8610009840 Knob N234
Screw PH BT M2 × 8 NI-ZU
MP9 8810008760
MP10 8930048910 2140 earth plate
MP11 8930049640 2141 plate
[MAIN UNIT]
REF. ORDER
NO. NO.
J2 6450000140 Connector HSJ0807-01-010
J5 6510018040 Connector 52330-1217
W4 8900004540 Cable OPC-453
MP1 8510006810 DC-DC case
MP2 8510009980 1705 VCO case
MP4 8510010080 1705 VCO cover
MP6 8930037840 1705 connector spring
MP7 8510005070 599 shield plate
MP8 8510010240 1705 LPF cover
MP9 8510010230 1705 LPF case
MP10 8510010250 1705 shield plate
MP11 8930029511 1327 ANT plate-1
MP12 8930038790 1706 spring
MP13 8930049590 Sheet (G)
MP14 8930057730 Shield sponge (J)
MP15 8930057730 Shield sponge (J)
MP16 8930056180 1706 rear spring
MP17 8930056180 1706 rear spring
MP18 8930056180 1706 rear spring
MP19 8930001160 Earth spring
MP20 8930005320 Filter spacer
MECHANICAL PARTS AND DISASSEMBLY
DESCRIPTION QTY.
[R&TTE] only
[R&TTE] only
DESCRIPTION QTY.
[BIIS]only
[OTHER]
DESCRIPTION QTY.
[R&TTE] only
[R&TTE] only
[R&TTE] only
[R&TTE] only
[R&TTE] only
[R&TTE (Middle-band)] only
[ACCESSORIES]
REF. ORDER
NO. NO.
1 F1 5210000120
1 MC1 0800005780
4
2 SP1 0800005120
2
4 W1 8900003751
1 W2 8900000730
3
1 MP1 8010016730
1 MP3 8820000530
1 MP4 8810000470
1 MP5 8810005840
1 MP6 8850000150
1 MP7 8850000390
1 MP8 8830000120
MP9 6910004210
MP10 8310054790
Screw abbreviations A, BT: Self-tapping
1
1
1
2
MC1 MP9
1
1
1
1
1
1
MP1
1
5
1
1
MP6 MP7
SP1
1
1
1
1
1
1
1
1
1
1
1
1
1
2
1
1
1
1
1
1
2
7 - 1
DESCRIPTION
Fuse FGB 15A
Microphone HM-100N
Speaker SP-22
Cable OPC-345
Cable OPC-049
150 mounting bracket
Flange bolt M4 × 8 NI
Screw PH M5 × 12 (+-)
Screw PH A M5 × 20
Flat washer M5 NI BS
Spring washer M5
Nut M5
731 MIC hanger set
1705 LCD seal (G)
PH: Pan head ZK: Black
BS: Brass NI: Nickel
NI-ZU: Nickel-Zinc
W1
W2
MP3
MP4
MP5
F1
MP8
QTY.
2
1
1
1
1
1
4
4
4
4
4
4
1
1
LCD-STICKER
MP10
