Technical Manual Presence Detector SCN-P360XX.01
2.6. Settings at the ETS‐Software
Selection at the product database:
Manufacturer: MDT Technologies
Product family: Presence Detectors
Product type: Ceiling
Medium Type: Twisted Pair (TP)
Product name: addicted to the used type, e.g.: SCN‐PM360K4.01, Presence Detector 360° Ceiling CL
4 sensors
Order number: addicted to the used type, e.g.: SCN‐PM360K4.01
The available parameters depend to the chosen product type. The additional functions for the plus
variant are not shown at the normal push buttons.
2.7. Starting up
After wiring the allocation of the physical address and the parameterization of every channel follow:
(1) Connect the interface with the bus, e.g. MDT USB interface
(2) set bus power up
(3) Press the programming button at the device(red programming LED lights)
(4) Loading of the physical address out of the ETS‐Software by using the interface(red LED goes
out, as well this process was completed successful)
(5) Loading of the application, with requested parameterization
(6) If the device is enabled you can test the requested functions(also possible by using the ETS‐
Software)
