3 Communication objects

3.1 Overview

The communication objects are divided into the categories of the submenus.
The objects 0‐12 are reserved for the lightgroups. The displayed objects and the length of the objects
change in accordance of the adjusted settings.
The object 14 is for the day/night switchover and can be activated via the general settings. Also the
object 15 – "Presence" can be activated in the general settings. The objects 16 and 17 refer to the
menu brightness in which the specific settings for this object can be done. They contain the current
measured brightness value and the threshold value.
After these objects, the objects for the Teach‐In function follows. The Teach‐In function is for the
internal brightness compensation, especially for the constant light function.
Then the objects 20‐28 follows, which are responsible for the constant light function. The object 29‐
"Output Heartbeat" can be parametrized in the general settings.
3.2 Default‐settings oft he communication objects
The following table shows the default settings of the communication objects:
Nr. Name
0 Output – Lightgroup 1
0 Output – Lightgroup 1
0 Output – Lightgroup 1
1 Output – Lightgroup 1
night mode
2 External Input –
Lightgoup 1
3 Input external Movement
– Lightgoup 1
4 Input – Lightgroup 1
5 Input – Lightgroup 1
6 Input – Lightgroup 1
+7 Light group 2
