Technical Manual Presence Detector SCN-P360XX.01
The following chart shows the relevant communication objects for the first light group:
Number Name
0 Output – light group 1
1 Output – light group 1
night mode
2 External Input – light group
1
3 Input external movement –
light group 1
4 Force control
4 Lock
5 Lock object ON
Table 7: Communication objects light
If a second light group is activated, the same communication objects with the same functionality are
shown.
The following table shows the relevant communication objects for a HCV channel:
Number Name
7 Output – climate (HCV)
8 External Input – climate
(HCV)
9 Input external movement –
climate (HCV)
10 Force control
11 Lock
12 Lock object ON
Table 8: Communication objects HCV
MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1
21
Tel.: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de
Length Usage
1 Bit/ Output for the first light group; Length and type
1Byte depends to the parameter Object type for output
1 Bit Output for the orientation light at night mode
1 Bit External input for Push Buttons/Indication object
of an actuator for switching the light
1 Bit External input for second detector
2 Bit Force control object; switches the detector as
described above
1 Bit Lock object; switches the detector as the
adjusted settings
1 Bit Lock object, which switches the detector on with
a 1‐command
Length Usage
1 Bit/ Output for the HCV group; Length and type
1Byte depends to the parameter Object type for output
1 Bit External input for Push Buttons/Indication object
of an actuator for switching the HCV group
1 Bit External input for second detector
2 Bit Force control object; switches the detector as
described above
1 Bit Lock object; switches the detector as the
adjusted settings
1 Bit Lock object, which switches the detector on with
a 1‐command
