Technical Data - BFI Automation CFC 200 Technical Description

Accessories
Power supply 230/115V AC
Swivel mount 1 inch and 2 inch flange disk
Heating insulator 1 inch
3-way ball cock 1 inch
Pressure screw joint 5bar size 1 inch
Optical adjusting device

Technical data

Spectral sensitivity
CFC 200 UV1 (formerly 8.0)
CFC 200 UV (formerly 8.30)
CFC 200 IR (formerly 8.40)
CFC 200 IR3 (formerly 8.70)
Visual aperture
Input voltage
Current consumption
Construction
Ambient temperature
Current output
Flame relay
Flame failure response time,
switch-off time
Sight tube connection
Purge air connection
Purge air quantity
Electrical connection
Standard
Flame proof housing
OE-Converter
EX-OE-Converter
Dimension
Standard with flange
Explosion proof housing
OE-Converter housing
Ex-OE-Converter housing
Triple Ex-OE-Converter
190 up to 550 nm
280 up to 420 nm
300 up to 1050 nm
1050 up to 2700 nm
2.7 degrees
24 V DC
approx. 200 mA
according to SELV III
-20°C...+70°C
0(4)...20 mA (Ra < 250 Ohm) flame intensity
1 change-over contact, potential free
VDE 0110, Class A
max. 48 V switching voltage
max. 1 A switching current (fused with 0.5 A)
max. 30 W switching power
switching point "flame on"5(8) mA
switching point "flame off"< 5(8) mA
1 second, factory preset
other switch off times on request
1" internal thread ISO 228
1/2" internal thread ISO 228
3
10 m /h at standard conditions
Harting connector HAN8 90 degrees
3m special cable
Harting connector HAN8 90 degrees
M20-screw joint and terminal clamps inside
235 x 108 mm (Length x Diameter)
223 x 120 mm (Length x Diameter)*
120 x 122 x 80mm (Length x Width x Height)*
232 x 232 x 166,5mm (Length x Width x Height)*
276 x 276 x 218mm (Length x Width x Height)*
*without plugs and mounting bracket
