primary air
mounting flange
flame scanner
optical
heating
adjustment
insulator
CAUTION:
!
ever parts are replaced, when the scanner has been moved, when the flame
shape has altered (additional fuels, new burners, burner/register modifica-
CAUTION
tions), as well as on new installations.
flame root
fuel
changing of frequency and amplitude in
relationship to the distance of the flame root
ball flange
sight tube
All alignment and adjustment procedures should be used when-
4
combustion area
how to adjust in the right way
adjustment angle
30° max
right
wrong
