Z-5R Web

2. SPECIFICATIONS

Keys memory
Events memory
Attached readers
Reader protocols
Reader indication control
Readers supply protection
Power output current
ALARM output signal
Tamper protection
Interface
Supported Frame Types
Supported Protocols
Supported Standards
Frequency Range
Transfer Rates
W ireless signal power
W ireless operation modes
W ireless security
USB Connector type
USB Version
USB Mode
W eight
Dimensions, mm
Mount
Power supply
Operational current (at 12V)
2x 8168 keys
8192 events
2
Wiegand (-26, -34, -42, -50),
iButton™
Red and Green LEDs, Audible Beep
200 mA
5 A
250 V, 100 mA, 35 Ohm, insulation
1.5 kV
Optical
Ethernet
RJ45
MDI/MDIX
Ethernet II, IEEE 802.3
IP, ARP, TCP, SSH, ICMP, UDP,
DHCP, HTTP
Wi-Fi
IEEE 802.11 b/g/n
2.4-2.4835 GHz
802.11n: up to 150 Mbps
802.11g: up to 54 M bps
802.11b: up to 11 M bps
Up to 20 dBm (100 mW )
Access point, Client
64/128/512-bit WEP, W PA, W PA-
PSK, W PA2, W PA2-PSK
USB
USB Type A
USB 2.0
Host, High Speed, Full Speed
Other Param eters
150 g
105 x 115 x 37
Wall, 35mm DIN rail (TH35)
8 – 28 V
Up to 300 mA (excluding readers)
www.ironlogic.me
(10/100BASE-T) Auto
