3. CONNECTION
The controller dimensions are presented on this Figure:
Caution: To avoid sharp edges in controller casing, use saw to remove the tabs covering holes for
leading wires through, rather than breaking the tabs out manually.
Dimensions for controller mounting:
104
99
80
www.ironlogic.me
37
page 3
