CommScope EHD User Manual page 18

TECP-91-008 • Rev C • January 2019
4. Based on cable location and number of sub-units, determine the configuration to
be used for routing cables to the EHD panel. Cables may enter the panel from
either side only or from both sides. For an example of single side entry, see
Figure
Note: Some cables are shipped with protective mesh tubing already installed as
shown in
EHD panel.
Page 18
© 2019 CommScope. All Rights Reserved.
20. For an example of left and right cable entry, see
Figure 20. Single Entry Cable Routing (Top View)
Figure 21. Left and Right Cable Routing (Rear View)
(Cables With Hook-and-Loops Shown)
Figure 22 at the cable clamp and in
Figure 21.
26428-A
Figure 23 at the entry point to the
