Globalsat TR-151A Quick Start Manual

Vehicle/asset tracker
Hide thumbs Also See for TR-151A:

Advertisement

Table of Contents

TR-151A /TR-151E
Vehicle/Asset Tracker

Quick Start Guide

0.1
Version

Install SIM card and Battery

Use a coin or screwdriver to loosen the screw on back cover.
Lift up the back cover and remove it as the direction shown.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TR-151A and is the answer not in the manual?

Questions and answers

Related Manuals for Globalsat TR-151A

Summary of Contents for Globalsat TR-151A

  • Page 1: Quick Start Guide

    TR-151A /TR-151E Vehicle/Asset Tracker Quick Start Guide Version Install SIM card and Battery Use a coin or screwdriver to loosen the screw on back cover. Lift up the back cover and remove it as the direction shown.
  • Page 2 Push forward the cover of SIM card slot to the position marked with “OPEN”. Then lift up the cover Insert the SIM card with its metal contacts facing down and the cut corner at the top left. Note: Before installing the SIM card, please disable the SIM PIN protection function (asks SIM PIN entry while turn on the device) by your cellular phone.

  • Page 3: Install The Usb Driver

    Install the USB driver TR-151 Insert the Driver CD into your CD-ROM driver. AutoRun installation window will appear. Click “Install USB Driver” button to install the USB driver. TR-151 page 3...

  • Page 4: Install The Call Center Program

    Install the Call Center program TR-151 Click “Install PC Software” button to install the Call Center program. Follow the instruction to complete the installation process. TR-151 page 4...
  • Page 5 TR-151 Setup Connect the USB cable to TR-151 and the USB port on your PC. Press power button 3~4 seconds to turn on the power of TR-151. The status LED will emit red light indicating it has already entered the setup mode. Start Call Center program.
  • Page 6 Write down the Module IMEI of your TR-151, you may need it later. Enter the information in “User Name”, “Phone Number”, and “SOS Number” fields. Press “OK” button and then unplug the USB cable from PC and TR-151. Press power button to turn off TR-151. Set DIP switch 3 to OFF.

  • Page 7: Getting Started

    Getting Started SOS function Step 1 Power on Red Status LED will flash 2 times. GSM LED begins to flash once per second. After TR-151 finish registration process in a few second, the LED will flash once per 3 second. (Note 1) (Note 2) GPS begins to get position fixed.
  • Page 8 Send command to TR-151 Step 1 Power on Red Status LED will flash 2 times. GSM LED begins to flash. GPS begins to get position fixed. GPS LED will be on. Step 2 We will have a “Period Report” ?1,355632002593292,60,0,1,626123456! example here.

This manual is also suitable for:

Tr-151e
