Market Forge Industries PS-3E Parts And Service Manual

Electric convection steamers
Hide thumbs Also See for PS-3E:

Advertisement

Quick Links

Download this manual See also: Owner's Manual, Installation Operation & Maintenance
PS-3E AND PS-6E
ELECTRIC CONVECTON STEAMERS
PARTS AND SERVICE MANUAL
EFFECTIVE AUGUST 1, 2014
Superseding All Previous Parts Lists.
The Company reserves the right to make substitution in the event that items specified are not available.
ERRORS: Descriptive and/or typographic errors are subject to correction.
MARKET FORGE
Telephone: (802) 658-6600 Fax: (802) 860-3732
www.marketforge.com
P/N 14-0285 Rev A (8/14)

Advertisement

loading
Need help?

Need help?

Do you have a question about the PS-3E and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Market Forge Industries PS-3E

Summary of Contents for Market Forge Industries PS-3E

  • Page 1 PS-3E AND PS-6E ELECTRIC CONVECTON STEAMERS PARTS AND SERVICE MANUAL EFFECTIVE AUGUST 1, 2014 Superseding All Previous Parts Lists. The Company reserves the right to make substitution in the event that items specified are not available. ERRORS: Descriptive and/or typographic errors are subject to correction.
  • Page 2 TABLE OF CONTENTS SERVICE AND ADJUSTMENTS ............3 WIRING DIAGRAMS .

  • Page 3: Service And Adjustments

    SERVICE AND ADJUSTMENTS • READY light does not come on after about 15 min- NOTICE utes, Contact the factory, the factory representa- • Water begins to overflow into cooking compartment, tive or local service company to perform any maintenance and repairs. •...
  • Page 4 WIRING DIAGRAMS...
  • Page 5 WIRING DIAGRAMS...
  • Page 6 WIRING DIAGRAMS...

  • Page 7: Illustrated Parts List

    ILLUSTRATED PARTS LIST AUGUST 1, 2014 PS-3E & PS-6E...
  • Page 8 97-6191 Door Switch 97-6178 Striker 97-6302 Stainless Steel Washer 97-6650 Lock Washer 97-6651 97-6270 Pilot Light, Green 97-6271 Pilot Light, Red **15 98-6046 Timer Dial 97-6272 Power Switch NOT SHOWN ** SELECT AS REQUIRED AUGUST 1, 2014 PS-3E & PS-6E...
  • Page 9 Terminal Rail, 208-240V, 15 kW 10-6963 Terminal Block, 380/220V 415/240V, Black 10-6963 Terminal Block, 380-600V, Black **34 10-6962 End Section, Black 98-6186 End Section, 208-240V, 15 kW, White NOT SHOWN ** SELECT AS REQUIRED AUGUST 1, 2014 PS-3E & PS-6E...
  • Page 10 Rack Pin Assembly 97-6341 Brass Nipple, 1/2 -14 97-6342 Brass Elbow, 1/2 -14 97-6740 Brass Plug, 1/2 - 14, Hex Head 97-6344 Connector, 3/8 c x 1/8 MPT NOT SHOWN ** SELECT AS REQUIRED AUGUST 1, 2014 PS-3E & PS-6E...
  • Page 11 Transformer, 600-240V, 60 Hz, 100VA 97-6663 Hex Blot, 5/16-18 x 1 SS 97-6298 Hex Nut, 1/4 - 20 SS 97-6349 “Y” Strainer, Optional 97-6741 Wire Harness 97-6351 Copper Tube, 3/8 NOT SHOWN ** SELECT AS REQUIRED AUGUST 1, 2014 PS-3E & PS-6E...
