3500 SERIES
CONVECTION STEAM COOKER
PARTS AND SERVICE MANUAL
EFFECTIVE JULY 30, 2014
Superseding All Previous Parts Lists.
The Company reserves the right to make substitution in the event that items specified are not available.
ERRORS: Descriptive and/or typographic errors are subject to correction.
MARKET FORGE INDUSTRIES
44 Lakeside Avenue, Burlington, Vermont 05401 USA Telephone: (802) 658-6600 Fax: (802) 860-3732
www.mfii.com
P/N 14-0280 Rev A (7/14)
Advertisement
Table of Contents
Related Manuals for Market Forge Industries 3500 SERIES
Summary of Contents for Market Forge Industries 3500 SERIES
- Page 1 3500 SERIES CONVECTION STEAM COOKER PARTS AND SERVICE MANUAL EFFECTIVE JULY 30, 2014 Superseding All Previous Parts Lists. The Company reserves the right to make substitution in the event that items specified are not available. ERRORS: Descriptive and/or typographic errors are subject to correction.
-
Page 2: Table Of Contents
POWER PLUS ............... 18 JULY 30, 2014 3500 SERIES CONVECTION STEAMERS... -
Page 3: Principles Of Operation
OFF position opens the con- partment in this manner until the control circuit closes the tact to the buzzer coil to shut it off. solenoid valve. JULY 30, 2014 3500 SERIES CONVECTION STEAMERS... - Page 4 195°F, thus assuring that cooking temperature ally turned to the OFF position, returning the common ele- exists throughout the timed duration. ment (1) of the timer switch to the neutral position. Figure 1 JULY 30, 2014 3500 SERIES CONVECTION STEAMERS...
-
Page 5: Troubleshooting
B. Faulty thermostat. Replace thermostat. (Refer to cooking compartment thermostatic switch section) C. Faulty cold water solenoid. Replace valve. D. Faulty wiring. Inspect condition of wire and tightness of all connections. Correct as needed. JULY 30, 2014 3500 SERIES CONVECTION STEAMERS... - Page 6 7. Buzzer fails to sound at end of 60 minute timer mode. A. 60 minute timer contacts. B. Buzzer. C. Wiring. 8. Steam flows continuously form boiler drain line. A. Thermostatic switch. B. Cold water solenoid valve. C. Wiring. JULY 30, 2014 3500 SERIES CONVECTION STEAMERS...
- Page 7 TROUBLESHOOTING - 3500 ONLY Figure 2 JULY 30, 2014 3500 SERIES CONVECTION STEAMERS...
- Page 8 TROUBLESHOOTING - 3500 POWER PLUS ONLY Figure 3 JULY 30, 2014 3500 SERIES CONVECTION STEAMERS...
- Page 9 “0 Minute.” If the motor fails to operate, it is defective and the entire timer must be replaced. 4. Shut off power to the cooker. JULY 30, 2014 3500 SERIES CONVECTION STEAMERS...
- Page 10 If voltage of 120 volts is present and the valve fails to open, the fault is in the valve coil. Defective valve coils are separately replaceable. JULY 30, 2014 3500 SERIES CONVECTION STEAMERS...
-
Page 11: Repair & Replacement
3. Tighten both nuts down until the springs are fully compressed. 4. Back each nut off 1/2 turn. 5. Remount the control panel, reconnecting wire plug and restraining wire. JULY 30, 2014 3500 SERIES CONVECTION STEAMERS... -
Page 12: Door Assembly
DOOR ASSEMBLY REF. PART DESCRIPTION 91-5286 DOOR GASKET 91-5745 DOOR HANDLE 09-1608 STRIKER 08-5027 MAGNET 91-5901 MAGNET BRACKET 08-4600 COMPRESSION SPRING JULY 30, 2014 3500 SERIES CONVECTION STEAMERS... -
Page 13: Cabinet Assembly
PANEL, LT. SIDE 91-6475 HINGE, TOP 91-6476 HINGE, BOTTOM 91-6492 LATCH, RECEIVER 91-6491 GROMMET 08-6538 VACUUM BREAKER 91-6940 RELAY BRACKET 91-7557 STEAM INLET ORIFICE PLATE 10-7545 ACORN NUTS FOR PLATE 91-7497 DRIP TROUGH (NOT SHOWN) JULY 30, 2014 3500 SERIES CONVECTION STEAMERS... - Page 14 CABINET ASSEMBLY JULY 30, 2014 3500 SERIES CONVECTION STEAMERS...
-
Page 15: Control Panel Assembly
CONTROL PANEL ASSEMBLY REF. PART DESCRIPTION 98-3504 CONTROL PANEL 98-3507 ARTWORK, CONTROL PANEL 08-6464 60 MIN. TIMER 08-6541 TERMINAL STRIP 91-6471 BRACKET, TERMINAL STRIP 10-7395 BUZZER 08-3826 KNOB, TIMER 10-5052 LIGHT, RED, ON/OFF JULY 30, 2014 3500 SERIES CONVECTION STEAMERS... -
Page 16: Condenser Assembly
BRAIDED HOSE, 1/4” x 42” LG., W/FITTINGS, STAINLESS STEEL* 98-4136 BRASS TEE, FLAREL 1/8” NPT** 98-4139 BRASS ELBOW, FLARE, 1/8” NOT** 98-4140 BRAIDED HOSE, 1/4” x 4” LG., W/FITTINGS, STAINLESS STEEL** FROM BOILER TO CONDENSTER VALVES (3500/ST-10) TO INTERCONNECT BOTH VALVES JULY 30, 2014 3500 SERIES CONVECTION STEAMERS... -
Page 17: Complete Condenser Assembly
Hose Barb, 90o, 1/8” IPS 08-1206 Hose Clamp 08-7923 Tee 1/8” NPT 08-4890 Hose Coupler, 1/8 IPS x 1/4 ID 91-6491 Grommet 08-4866 Spray Nozzle (3500 ONLY) 08-4821 Condenser Solenoid (3500 ONLY) 91-7640 Condenser Bracket JULY 30, 2014 3500 SERIES CONVECTION STEAMERS... -
Page 18: Power Plus
POWER PLUS REF. PART DESCRIPTION 10-9175 RELAY SOCKET, (ONE PER COMPARTMENT) 10-9174 CUBE RELAY, (ONE PER COMPARTMENT) 08-6502 PRESSURE SWITCH 98-4206 POWER SUPPLY, 5 VDC 97-6455 TIME DELAY RELAY JULY 30, 2014 3500 SERIES CONVECTION STEAMERS...
