Defi -Link Advance Operation Manual page 77

Condition
○ The illumination
of CR/RS gauges
is not lighted. The
illumination of BF/
A1 gauges is not
darkened.
○ Does not carry out
the ending mode.
○ The needle pointer
is not around right
under 0 before
starting installation
with power off.
Possible Cause
○ The ILM wiring is improper.
○ The locks of the solderless con-
nectors are not locked tightly.
○ The illumination of gauge is set
to off (illumination cancel).
○ The dimmer setting of ZD is
AUTO and vehicle is in bright
light.
○ The battery wiring is improper. ○ Check wiring of +B as per
○ The needle pointer moved in
transit.
○ Check wirings of ILM as per
instructions in this manual.
○ Check the lock of the solder-
less connectors.
○ Release illumination cancel
function as per instructions
in this manual.
○ Change the dimmer setting
to MANUAL or move vehicle
to a dark place.
instructions in this manual.
○ Check the solderless con-
nector of battery wiring.
○ Ask the store for inspection.
○ It is the unique feature of
stepping motor that the
needle pointer may move
when a slight impact is
made to the gauge with
electricity off. Check if the
needle pointer goes back to
around 0 when the ignition
is turned from on to off. If
it does not, please contact
the store or our customer
service center.
76
Corrective Action
